tracer2000 Network DVR Hardware User’s Manual
Version 3.1
Page 4 of 31
Chapter III
Installation
Front Panel View
Rear Panel View
Alarm
Menu
Display
Playback
Confirm
Removable Air Filter Bracket
Removable Air
Filter Bracket
IR
UP
LEFT RIGHT
DOWN
Power/
HDD
LED
Remove and clean up Air Filters monthly is essential.
Power Supply
Parallel Port
BNC
Connector
GPIO
VGA
USB Ports x 2
10/100 Ethernet Port
MIC and
Speaker Out
COM1
COM2
Audio
