Grizzly Vertical Mill G0667X - Manual (Page 8)

<%++,M=^\]EgZX^h^dcKHKZgi^XVaB^aa
"+&"
Ram Breakdown & Parts List
*%&
*%'
*%(
*%)
*%*
*%+
*%,
*%-
*%.
*&%
*&&
*&'
*&(
*&)
*&*
*&+
*&,
*&-
*&.
*'%
*'&
*''
*'(
*')
*'*
*'+
*',
*'-
*'.
*(%
*(&
*('
*((
*()
*(*
*(+
*%)
*&%
*&*
*%)
*%)
REF PART # DESCRIPTION REF PART # DESCRIPTION
501 PSB31M CAP SCREW M8-1.25 X 25 519 P0667X0519 BUSHING
502 P0667X0502 DOWEL PIN 8 X 30 520 P0667X0520 VERTICAL ADJ WORM SHAFT
503 P0667X0503 GEAR 33T 521 P0667X0521 LIFTING EYE BOLT 3/4-10
504 P0667X0115 RIVET 522 P0667X0522 RAM
505 P0667X0505 SCALE 523 P0667X0523 RAM GIB
506 P0667X0506 RAM ADAPTER 524 P0667X0524 TURRET CLAMP BOLT
507 P0667X0507 INDICATOR PLATE 525 P0667X0525 RAM PINION SCREW
508 P0667X0508 WORM THRUST WASHER 526 P0667X0526 TURRET
509 P0667X0509 UPPER WORM LOCK COLLAR 527 P0667X0527 GIB ADJUSTMENT SET SCREW
510 PSS02M SET SCREW M6-1 X 6 528 PN08 HEX NUT 3/8-16
511 PK36M KEY 5 X 5 X 50 529 P0667X0529 RAM LOCKING PLUNGER
512 P0667X0512 VERTICAL ADJUSTING WORM 530 P0667X0530 HANDLE SHAFT
513 P0667X0513 SCALE 531 P0667X0531 HANDLE
514 P0667X0514 ADAPTER LOCKING BOLT 532 P0667X0532 SCREW SLEEVE
515 P0667X0515 FLAT WASHER 13MM 533 P0667X0533 SPECIAL SCREW
516 P0667X0516 LOCKING BOLT HEX NUT 534 P0667X0534 RAM PINION 13T
517 PR19M EXT RETAINING RING 28MM 535 P0667X0535 SCALE
518 P0667X0518 ADAPTER PIVOT ROD 536 P0667X0536 TURRET SPINDLE
