<%++,M=^\]EgZX^h^dcKHKZgi^XVaB^aa
"*."
Drive System Parts List
REF PART #
DESCRIPTION
REF PART #
DESCRIPTION
301
P0667X0301
SPANNER NUT
351
PS05M
PHLP HD SCR M5-.8 X 8
302
P0667X0302
SPANNER NUT WASHER
352
P0667X0352
SQUARE WASHER
303
P0667X0303
DEEP GRV BALL BEARING 6007VV
353
P0667X0353
OIL CUP 1/8"
304
P0667X0304
BUSHING
354
P0667X0115
RIVET
305
P0667X0305
TIMING BELT 720-BYU-25
355
P0667X0355
DATA PLATE
306
P0667X0306
SPINDLE PULLEY
356
P0667X0356
DBL END THREADED STUD 7/16-14
307
P0667X0307
SPINDLE PULLEY BOTTOM CAP
357
PLW05
LOCK WASHER 7/16
308
PS68M
PHLP HD SCR M6-1 X 10
358
PN19
HEX NUT 7/16-14
309
P0667X0309
BRAKE BEARING CAP
359
P0667X0359
SPECIAL HEX NUT
310
PS11M
PHLP HD SCR M6-1 X 16
360
P0667X0360
BELT PULLEY GEAR 50T
311
P0667X0311
BRAKE SHOE PIVOT SLEEVE
361
PSB24M
CAP SCREW M5-.8 X 16
312
PS12M
PHLP HD SCR M3-.5 X 6
362
P0667X0362
BULL GEAR PINION BEARING CAP
313
P0667X0313
BRAKE SPRING
363
P0667X0363
WAVY LOCK WASHER
314
P0667X0314
BRAKE SHOE ASSEMBLY
364
P0667X0364
DEEP GRV BALL BEARING 6203VV
315
P0667X0315
DEEP GRV BALL BEARING 6010VV
365
P0667X0365
PINON GEAR 26T
316
P0667X0316
BRAKE LOCK BRACKET
366
PSS20M
SET SCREW M8-1.25 X 8
317
PSS26M
SET SCREW M5-.8 X 6
367
P0667X0367
PINON GEAR SHAFT
318
P0667X0318
BRAKE LOCK PIN
368
PK19M
KEY 5 X 5 X 14
319
P0667X0319
BRAKE HANDLE
369
PK14M
KEY 5 X 5 X 18
320
P0667X0101
KNOB 3/8-16
370
P0667X0370
GREASE FITTING 1/8"
321
P0667X0321
BRAKE LOCK SHAFT
371
P0667X0371
GEAR HOUSING
322
P0667X0322
SHAFT SLEEVE
372
PSB14M
CAP SCREW M8-1.25 X 20
323
PSS03M
SET SCREW M6-1 X 8
373
P0667X0373
DATA PLATE
324
PR47M
EXT RETAINING RING 13MM
374
P0667X0374
BULL BEAR SHIFT PINION
325
P0667X0325
BRAKE SHAFT
375
P0667X0375
HI-LOW DETENT PLATE
326
P0667X0326
BRAKE PIVOT BRACKET
376
PSB33M
CAP SCREW M5-.8 X 12
327
PR36M
EXT RETAINING RING 7MM
377
PRP02M
ROLL PIN 3 X 16
328
P0667X0328
FEED TRIP BRACKET
378
P0667X0378
HI-LOW PINION BLOCK
329
PSB01M
CAP SCREW M6-1 X 16
379
PSB41M
CAP SCREW M4-.7 X 14
330
P0667X0330
SPINDLE PULLEY SPACER
380
P0667X0380
HI-LOW DETENT PLUNGER
331
P0667X0331
SPINDLE PULLEY GEAR SHAFT 18T
381
P0667X0381
COMPRESSION SPRING
332
PK109M
KEY 7 X 7 X 35
382
P0667X0382
HANDLE
333
PK27M
KEY 7 X 7 X 25
383
P0667X0118
KNOB 1/4-20
334
P0667X0334
TIMING BELT 225L-100
384
P0667X0384
SPINDLE MOTOR 3HP 220V 3-PH
335
P0667X0335
SPINDLE PULLEY HUB COLLAR
384-1 P0667X0384-1 MOTOR FAN COVER
336
P0667X0336
GEAR HOUSING TOP CAP
384-2 P0667X0384-2 MOTOR FAN
337
PK70M
KEY 8 X 8 X 12
384-3 P0667X0384-3 MOTOR WIRING JUNCTION BOX
338
P0667X0338
SPLINE BULL GEAR HUB
385
PSB111M
CAP SCREW M12-1.75 X 35
339
P0667X0339
SPINDLE BULL GEAR 81T
386
PW06M
FLAT WASHER 12MM
340
P0667X0340
BEARING SLEEVE
387
P0667X0387
MOTOR ADJUSTMENT LEVER
341
P0667X0341
DEEP GRV BALL BEARING 6908VV
388
P0667X0388
KNOB 5/16-18
342
P0667X0342
BULL GEAR BEARING SPACER
389
P0667X0389
KEY 8 X 7 X 30
343
P0667X0343
BEARING SLEEVE
390
P0667X0390
MOTOR GEAR 44T
344
PR38M
INT RETAINING RING 62MM
391
P0667X0391
SPECIAL WASHER
345
P0667X0345
WAVY LOCK WASHER
392
PSB31M
CAP SCREW M8-1.25 X 25
346
P0667X0346
SPANNER NUT WASHER
393
P0667X0393
TOP BEARING COVER
347
P0667X0347
SPANNER NUT
394
PSB02M
CAP SCREW M6-1 X 20
348
P0667X0348
SPACER
395
P0667X0395
MOTOR ADJUSTMENT BLOCK
349
P0667X0349
SPECIAL PIN
396
PSB12M
CAP SCREW M8-1.25 X 40
350
P0667X0350
COMPRESSION SPRING
397
P0667X0397
DRIVE SYSTEM HOUSING
