Grizzly H7947/H7948 - Manual (Page 17)

H7947/H7948 16 Gauge Stapler -15 -
H7947 PARTS LIST
REFPART # DESCRIPTION REFPART # DESCRIPTION
1 PFH06M FLAT HD CAP SCR M6-1 X 20 41 PH7947041 CONTACT TRIP BLOCK
2 PH7947002 FRONT BRACKET 42 PH7947042 ADJUSTING BLOCK
3 PH7947003 EXHAUST COVER 43 PH7947043 CONTACT ARM
5 PH7947005 EXHAUST FILTER PLATE 44 PSB33M CAP SCREW M5-.8 X 12
6 PSB38M CAP SCREW M5-.8 X 25 45 PH7947045 DRIVER GUIDE PLATE
7 PH7947007 CAP 46 PRP04M ROLL PIN 4 X 24
8 PH7947008 SPRING 47 PSB79M CAP SCREW M5-.8 X 32
9 PH7947009 O-RING 48 PH7947048 SET BLOCK
10 PH7947010 WASHER 49 PH7947049 CAP SCREW M3-.6 X 16
11 PH7947011 PISTON HEAD VALVE 50 PH7947050 NOSE
12 PH7947012 O-RING 51 PH7947051 MAGAZINE COVER
13 PH7947013 SEAL 52 PH7947052 STAPLE GUIDE
14 PH7947014 PLAIN WASHER 53 PSB33M CAP SCREW M5-.8 X 12
15 PH7947015 PISTON STOPPER 54 PH7947054 SPRING
16 PH7947016 O-RING 55 PH7947055 STOPPER
17 PH7947017 PISTON 56 PH7947056 BUTTON HD CAP SCR M5-.8 X 60
18 PH7947018 DRIVER 57 PH7947057 MAGAZINE
19 PH7947019 CYLINDER 58 PH7947058 SPIRAL SPRING
20 PH7947020 O-RING 59 PH7947059 FLAT HD SCR M3-.5 X 5
21 PH7947021 CYLINDER RING 62 PH7947062 PUSHER GUIDE
22 PH7947022 COLLAR 63 PH7947063 O-RING
23 PH7947023 O-RING 64 PH7947064 O-RING
24 PH7947024 GASKET 65 PH7947065 TRIGGER VALVE HOUSING
25 PH7947025 BODY 66 PH7947066 BALL PIN
26 PH7947026 PAD 67 PH7947067 O-RING
27 PH7947027 SET PLATE 68 PH7947068 PILOT VALVE
28 PH7947028 BOTTOM BUMPER 69 PH7947069 O-RING
29 PRP97M ROLL PIN 3 X 30 70 PH7947070 O-RING
30 PH7947030 RUBBER GRIP 71 PH7947071 SPRING
31 PSB24M CAP SCREW M5-.8 X 16 72 PH7947072 PLUNGER
32 PH7947032 O-RING 73 PH7947073 O-RING
33 PH7947033 COVER 74 PH7947074 TRIGGER VALVE CAP
34 PH7947034 SPRING 75 PH7947075 O-RING
35 PH7947035 TRIGGER PLATE 76 PW02M FLAT WASHER 5MM
36 PH7947036 TRIGGER 77 PH7947077 MACHINE LABEL
37 PRP02M ROLL PIN 3 X 16 78 PH7947078 STAPLER CASE
38 PH7947038 SLIDE SHAFT 79 PH7947079 INCLUDED PNEUMATIC OIL
39 PH7947039 TRIP GUIDE 80 PAW04M INCLUDED HEX WRENCH 4MM
40 PH7947040 SPRING 81 PH7947081 PISTON REPAIR KIT
