Model G5352 Spray Gun
-14
-
Lubrication
Lubricate the following areas with a non-
silicon spray gun lubricant after cleaning.
A. Atomizing Cap Threads
B. Air Valve Packing
C. Trigger Pin
D. Air Flow Control Valve
E. Pattern Control
F. Fluid Control Knob
Allow the lubricant to coat threads, and run
into gun body to lubricate all moving parts
and seals.
Figure 14. Lubrication points.
A
B
C
D
E
F
