4 Quick Start
Caution: READ SECTION 6 TITLED BATH USE before placing the bath
in service. Incorrect handling can damage the bath and void the warranty.
This chapter gives a brief summary of the steps required to set up and operate
the bath. This should be used as a general overview and reference and not as a
substitute for the remainder of the manual. Please read Section 5 through 8
carefully before operating the bath.
4.1 Unpacking
Unpack the bath carefully and inspect it for any damage that may have oc-
curred during shipment. If there is shipping damage, notify the carrier immedi-
ately. Verify that all components are present:
•
CTR –80 Bath
•
Access Hole Cover
•
Manual
•
RS-232 Cable
•
Report of Test
•
Drain Valve
4.2 Set-up
Caution: The drain valve must be installed on the back of the bath before
attempting to fill the tank with fluid. See Section 5.3, on page 17 for drain
installation instructions.
Warning: The instrument is equipped with a soft cutout (user settable firm-
ware) and a hard cutout (set at the factory). Check the flash point, boiling
point, or other fluid characteristic applicable to the circumstances of the
unit operation. Ensure that the soft cutout is adjusted to the fluid charac-
teristics of the application. As a guideline, the soft cutout should be set
10°C to 15°C below the flash point of the bath fluid. See Section , Heat
Transfer Fluid, for specific information on bath fluids and Section , Cut-
out.
