Parts list – control panel – Generac 9801-7 User Manual
Page 21
21
10000EXL Extended Life Generator
PARTS LIST – CONTROL PANEL
Item Part #
Qty Description
1
AB4432GS
1 PANEL, Control
2
B95906GS
1 BOX, Control
3
43437GS
1 OUTLET, 120/240V, 30A Locking
4
68759GS
1 OUTLET, 120V, 20A Duplex
5
68868GS
1 OUTLET, 120V, 30A Locking
6
B5112GS
1 ASSY, Diode
7
186102GS
1 ASSY, Engine Harness
8
90576GS
1 GROMMET, Rubber
9
B4262GS
1 OUTLET, 120/240V 50A
10
87962GS
1 BREAKER, Circuit
11
93929GS
4 STAND OFF
12
51715GS
12 NUT
13
22264GS
16 WASHER, Lock
14
43181GS
10 SCREW
16
38150GS
20 WASHER
17
23365GS
12 WASHER
18
90418GS
1 OUTLET, 12V DC
19
43182GS
10 WASHER, Lock
20
75207AGS
2 BREAKER, Circuit, 30A
21
78653GS
1 SWITCH, Run - Stop
22
93986GS
8 SCREW
23
91526GS
4 SCREW
24
49226GS
5 WASHER, Lock
25
23897GS
5 WASHER
26
75207GS
3 BREAKER, Circuit, 20A
27
74190GS
1 OUTLET, 120V/20A
28
92953GS
1 BLOCK, 50 Amp, 3 - Terminal
29
80077GS
4 SCREW
30
94117GS
1 BOARD, Idle Control
31
84028GS
1 TRANSFORMER, Idle Control
32
65795GS
1 RECTIFIER, Battery Charge
33
84135GS
1 GROMMET, Rubber
34
79224GS
1 SCREW
35
186200GS
1 RESISTOR
36
B4893GS
4 STAND OFF
37
82538GS
1 SWITCH, On - Off
38
51714GS
4 NUT
39
51716GS
1 NUT
40
B4445GS
2 BREAKER, Circuit, 45A
41
B4894GS
1 RECTIFIER, Battery Charge
42
77314GS
1 RELAY, 3A Thermal
43
B4892GS
1 RESISTOR
44
27565GS
1 TAPE, Glass Insulation
