Parts list – main unit – Generac 9801-7 User Manual
Page 19
19
10000EXL Extended Life Generator
Item Part #
Qty Description
1
NSP
1
ENGINE
2
JB4509AGS
1
SHIELD, Heat
3
A77304GS
2
SUPPORT, Engine
4
JB5567GS
1
SHIELD, Heat
5
80270GS
1
VALVE, Fuel Shut-Off
6
78299GS
1
BUSHING, Fuel Valve
7
B4325GS
1
CAP, Fuel Tank
8
38353GS
6
MOUNTS,Vibration
9
78831BGS
4
SCREW
10
B1997GS
1
ASSY,Tank, Fuel (Includes Items 5 & 6)
11
A189487GS
1
CRADLE
12
83465GS
4
GROMMET, Fuel Tank Mounting
13
87680GS
1
SCREW,Wing
14
23152GS
6
SCREW
15
22237GS
16 WASHER, Lock
16
22241GS
6
NUT
17
77816GS
2
DECAL, Caution Hot Muffler
18
22131GS
2
WASHER
19
J93074GS
1
SHIELD, Heat
20
186076GS
1
ASSY, Control Panel (see pages 20-21)
21
19553621GS
1
ASSY,Wire, Ground
22
45757GS
1
SCREW
23
75246GS
4
SCREW
24
22145GS
6
WASHER
25
26850GS
3
WASHER
26
20566GS
1
DECAL, 1-800
27
B4986GS
1
DECAL, Ground
28
92982GS
1
DECAL, Danger
29
189409GS
2
DECAL, Unit
31
52857GS
1
NUT, Lock
32
187049GS
1
PLUG, Dome
33
93826GS
1
DECAL, Start Instructions
34
76040GS
1
SCREW
35
B2153GS
19 SCREW
36
73054GS
1
DECAL, Fuel Shut-Off
37
B4268GS
1
ALTERNATOR (see page 23)
38
A5850GS
1
U-CHANNEL
39
96867GS
1
ASSY, Stepper Motor
40
B4489GS
1
BATTERY
41
39253GS
2
SCREW
42
22129GS
2
WASHER, Lock
43
A96925GS
1
BRACKET, Battery Tie Down
44
96924GS
2
J-BOLT
45
189302DGS
1
CABLE, Battery Positive
46
19753621GS
1
CABLE, Battery Negative
47
23897GS
2
WASHER
48
49226GS
1
WASHER, Lock
49
52856GS
2
NUT, Lock
50
49820GS
2
NUT, Nylok
51
42907GS
1
SCREW
52
49813GS
1
NUT
54
27482GS
1
WASHER
55
47411GS
1
SCREW
56
22473GS
1
WASHER
Item Part #
Qty Description
57
55934TGS
1
CLAMP, Hose
58
55934GGS
2
CLAMP, Hose
59
22511GS
6
SCREW
60
96832GS
1
CLAMP, Hose
61
52618GS
3
SCREW
62
B4794GS
1
GROMMET, Generator Cover
63
33141GS
1
SCREW
64
30340GS
1
HOSE
65
48031CGS
2
CLAMP, Hose
66
62265GS
1
GROMMET, Rubber
67
95349GS
1
PLATE, Adjust
68
96717GS
1
SPRING
69
95921GS
1
LINKAGE, Bell Crank to Throttle
70
75477GS
2
SCREW
71
96716GS
3
WASHER, Nylon
72
95348GS
1
BRACKET, Bell Crank
73
96378GS
1
SPACER
74
51713GS
1
WASHER
75
49226GS
1
WASHER, Lock
76
95920GS
1
LINKAGE, Stepper Motor to Bell Crank
77
22287GS
2
SCREW
78
188987GS
1
BRACKET, Starter Switch
79
23762GS
2
WASHER
80
77282GS
1
SWITCH, Starter
81
189302AGS
1
ASSY,Wire
82
22097GS
4
WASHER, Lock
83
22127GS
4
NUT
84
186102GS
1
WIRE, Harness
85
188989GS
1
ASSY, Jack, DC
86
189198GS
1
DECAL, Instruction, ES
87
58359GS
1
LUG
88
189484GS
1
MANUAL, Owners
89
191460GS
1
MANUAL, Engine
90
B4605GS
2
GRIP
91
BB5586GS
2
HANDLE (Includes Item 90)
92
187104GS
4
WASHER, Nylon
93
B4135GS
2
PIN, with Lanyard
94
39287GS
2
SCREW
95
B4177GS
1
CHARGE, Battery Float
96
49820GS
2
NUT, Nylok
97
43438GS
1
PLUG, 120/240V, 30A, 4 Prong
98
93568GS
1
PLUG, 125V, 20A
99
37806GS
1
PLUG, 120V/30A, 3 Prong
100
189505GS
1
FILTER, Oil
101
B4767GS
1
COVER, Storage
102
65787GS
1
CABLE, Battery Charge
103
189482GS
1
ELEMENT, Air Filter
104
189481GS
1
PRE-CLEANER, Air
105
189506GS
2
SPARK PLUG
106
B3518GS
1
CAP, Funnel, Oil Bottle
107
BB3061GS
2
BOTTLE, Oil
Optional Accessories Not Included:
84883GS
Cord Wrap
PARTS LIST – MAIN UNIT
