HandyTone-496 User Manual Grandstream Networks, Inc.
2 Installation
HandyTone-496 Analog Telephone Adaptor is an all-in-one VoIP integrated device designed to be a
total solution for networks providing VoIP services.
The HandyTone-496 VoIP functionalities are available via regular analog telephones.
The following photo illustrates the appearance of a HandyTone-496.
Top View Side Views
BUTTON
RED LED
GREEN LED
RJ45
10M Ethernet
LAN - WAN
RJ11
FXS Port
(Phone)
+5V/1200mA
RJ11
FXS Port
(Phone)
Interconnection Diagram of the HandyTone-496:
Fax
Cordless Phone
Analog Phone
Internet ADSL/Cable
Modem Ethernet
PC PC PC
LAN
WAN
FXS 1 FXS 2
Analog Phone
Cordless Phone
Fax
5
