Grandstream Networks HandyTone-496 - Manual (Page 23)

HandyTone-496 User Manual Grandstream Networks, Inc
.
23
Two FXS SIP accounts each has its own configuration page. Their configurations are identical. The
following is a screen shot of FXS Port 1 Account settings.
Grandstream Device Configuration
STATUS BASIC SETTINGS ADVANCED SETTINGS FXS PORT1 FXS PORT2
SIP Server:
sip.mycom om pany.c
(e.g., sip.mycompany.com, or IP address)
Outbound Proxy:
(e.g., proxy.myprovider.com, or IP address, if any)
SIP User ID: 3123320
(the user part of an SIP address)
Authenticate ID:
3123320
(can be identical to or different from SIP User ID)
Authenticate Password:
(purposely not displayed for security protection)
Name:
John Doe
(optional, e.g., John Doe)
Use DNS SRV:
No Yes
User ID is phone number:
No Yes
SIP Registration:
No Yes
Unregister On Reboot:
No Yes
Register Expiration:
60
(in minutes. default 1 hour, max 45 days)
local SIP port:
5060
(default 5060)
local RTP port:
5004
(1024-65535, default 5004)
Use random port:
No Yes
DTMF Payload Type: 101
Send DTMF:
in-audio via RTP (RFC2833) via SIP INFO
Send Flash Event:
No Yes (Flash will be sent as a DTMF event if set to Yes)
Enable Call Features:
No Yes (if Yes, Call Forwarding & Call-Waiting-Disable are supported locally)
Offhook Auto-Dial:
(User ID/extension to dial automatically when offhook)
Proxy-Require:
Disable Call-Waiting:
No Yes
Preferred Vocoder:
(in listed order) choice 1:
current setting is " PCMU"
