SW3 switches 1 to 8

The switch positions on SW3 are for selecting the Ethernet device
type.

These switches are reserved for technical support. Do not use.

SW4 switches 7 and 8

Switches 7 and 8 on switch 4 control the communication protocol
between the PBe at port 1 and the DVR or PC. Normally this is
set at RS-232.

Table 5.

SW3 switches 1 to 8 - Device type

SW3

Switch function

1

2

3

4

5

6

7

8

Ethernet Analyzer

U

U

U

U

U

U

U

U

Generic

U

U

U

U

U

U

U

D

Native ATM

U

U

U

U

U

U

D

U

Verifone POS

U

U

U

U

U

U

D

D

Table 6.

SW4 switches 7 and 8 - communication protocol

SW4

Communication protocol

7

8

RS-232

D

U

RS-485

U

D
