model g0634z manual insert (mfg. 5/09+)
-7-
table assembly
&%'
&%*
&&%
&%&
&%(
&&'
&%+
&%,
&&(
&%-
&%- &%.
&%.
&&*
&&+
&'' &&-
&&)
&'%
&'&
&'%
&'&
&'+
&')
&&,
&'*
&')
&&,
&'*
&((
&%.
&(%
&('
&(&
&'.
&((
&%.
&(%
&('
&(&
&()
&'&
&'&
&'.
&&&
&&(
&&)
&&.
&(*")
&(*"-
&(*"*
&)(
&))
&)(
&%)"'
&'-
&',
REF
PART #
DESCRIPTION
REF
PART #
DESCRIPTION
101
P0633101
INFEED TABLE
120
PW07
FLAT WASHER 5/16
102
P0633102
OUTFEED TABLE
121
PCAP07
CAP SCREW 5/16-18 X 3/4
103
P0633103
TABLE LIP
122
PB31
HEX BOLT 1/4-20 X 1
104-2 P0633104-2
JOINTER DUST PORT
124
PCAP19
CAP SCREW 3/8-16 X 1-1/4
105
P0633105
HINGE SHAFT A
125
PN02
HEX NUT 5/16-18
106
P0633106
HINGE SHAFT B
126
PCAP04
CAP SCREW 1/4-20 X 1/2
107
P0633107
OUTFEED TABLE ADJ. KNOB
127
P0633127
PLASTIC PLUG
108
P0633108
GUIDE SCREW
128
PCAP45
CAP SCREW 5/16-18 X 3/8
109
PN01
HEX NUT 1/2-20
129
P0633129
HANDLE
110
P0633110
INFEED HANDGRIP
130
P0633130
SPECIAL SCREW 1/2
111
P0633111
INFEED LOCK LEVER
131
P0633131
PLUNGER
112
P0633112
OUTFEED LOCK LEVER
132
P0633132
COMPRESSION SPRING
113
P0633113
PLASTIC KNOB
133
P0633133
KNOB
114
PR03M
EXT RETAINING RING 12MM
134
G2405
PUSH BLOCK-SMALL (2 PIECES)
115
P0633115
CUTTERHEAD GUARD BRACKET
135-4 P0633215-4
L BRACKET
116
PW06
FLAT WASHER 1/4
135-5 P0633215-5
PLATE
117
PB07
HEX BOLT 5/16-18 X 3/4
135-8 P0633215-8
PLATE
118
P0633118
KNOB SCREW 1/4-20 X 1
143
PS01
PHLP HD SCR 10-24 X 1/2
119
PS18
PHLP HD SCR 10-24 X 1/4
144
PN07
HEX NUT 10-24
