18
Note. To cut to the left-hand side of the blade, align the left-
hand laser line with the pencil mark. To cut to the right-hand
side of the blade, align the right-hand laser line with the
pencil mark.
5. Plug in the machine and start the motor.
6. Press the release latch (31).
7. When the blade is at its maximum speed (approximately
2 seconds), lower the blade through the workpiece.
8. After completing the cut, switch off the laser light on/off
switch (2).
9. After each use, clean the laser light assembly (1) as
described below:
• Switch off the laser light switch (2) and then remove the
plug from the power point.
• With the saw arm (5) in the raised position, use a
soft brush to dust away the sawdust build-up around
the assembly.
Note. Wear eye protection whilst brushing the dust away.
Maintenance
WARNING. Always ensure that the tool is switched off and
the plug is removed from the power point before making
and adjustments or maintenance procedures.
Power cord maintenance
If the supply cord needs replacing, the task must be carried
out by the manufacturer, the manufacturer’s agent, or an
authorised service centre in order to avoid a safety hazard.
Cleaning
1. Keep the tool’s air vents unclogged and clean at all times.
2. Remove dust and dirt regularly. Cleaning is best done
with a soft brush or a rag.
3. Re-lubricate all moving parts at regular intervals.
4. Never use caustic agents to clean plastic parts.
CAUTION. Do not use cleaning agents to clean the
plastic parts of the saw. A mild detergent on a damp cloth
is recommended.
General inspection
Regularly check that all the fixing screws are tight. They
may vibrate loose over time.
