T ABLE 8: S TATUS P AGE
MAC Address The device ID, in HEX format. This is very important ID for ISP troubleshooting. LAN and
WAN Mac addresses will appear in this place. The LAN MAC address will be used for
provisioning and can be found on the label coming with original box and on the label
located on the bottom panel of the device.
WAN IP Address This field shows WAN IP address of HT502.
Product Model This field contains the product model info.
Software Version Program: This is the main software release. This number is always used for firmware
upgrade. Current release is 1.0.1.21 Boot and Loader are seldom changed.
Bootloader: current version is 1.0.0.9.
Core: current version 1.0.0.25
Base: current version is 1.0.0.76
System Up Time Shows system up time since the last reboot.
PPPoE Link Up Indicates whether the PPPoE connection is up if the HT502 is connected to DSL modem.
NAT This filed indicates the type of NAT connection used by the HT502 via its WAN port.
Port Status Displays relevant information regarding the each FXS port.
Port Hook Registration DND Forward Busy
Forward
Delayed
Forward
FXS1 On Hook Registered Yes 613
FXS2 On Hook Registered No 614
• Both FXS port1 and FXS port2 are registered with this SIP Server.
• FXS Port 1 user has set Do Not Disturb.
• FXS Port 1 user has set his calls to be forwarded unconditionally to ext 613.
• FXS Port 2 user has set his calls to forward to 614 when his phone is busy.
Advanced User Configuration
Log in to the advanced user configuration page the same way as for the basic configuration page. The
password is case sensitive and the factory default password for Advanced User is “admin”.
Advanced User configuration includes the end user configuration and the advanced configurations
including: a) SIP configuration, b) Codec selection, c) NAT Traversal Setting and d) other miscellaneous
configuration. HT502 each FXS SIP account has its own configuration page. Their configurations are
identical.
T ABLE 9: A DVANCED S ETTINGS
Admin Password This contains the password to access the Advanced Web Configuration page. This field is
case sensitive. Only the administrator can configure the “Advanced Settings” page.
Password field is purposely left blank for security reasons after clicking update and saved.
The maximum password length is 25 characters.
Layer 3 QoS This field defines the layer 3 QoS parameter which can be the value used for IP
Precedence or Diff-Serv or MPLS. Default value is 48.
