On the Water
36
Appendix A
Specifi cations
Physical
Case: Fully gasketed, high-impact plastic alloy
Display: 3.3” x 2.0” (8.3 x 5 cm) 160 H x 100 W pixels, FSTN LCD with
amber LED backlighting
Size: 4.93” H x 6.3” W x 2.7” D (12.5 x 13.5 x 6.9 cm)
Weight: 13 oz.
Temperature Range: +5° to 158°F (-15°C to 70°C)
Waterproof: IEC 529, level IPX-7 (submerged to 1 meter for 30 minutes)
Power
Input: 10 to 18 VDC with High Voltage Protection
Usage: 7 watts maximum
Nominal: 12 VDC @ 0.28 amps
Performance
Sonar Power Output: 300 watts (RMS), 2400 watts (peak to peak)
Frequency: 200/50 kHz (10°/40°)
Depth 1200 foot max depth*
NMEA
Support: NMEA 0183 Versions 2.0 - 2.3
Output Sentences: DBT, DPT, NTW, VHW
* Depth capability is dependent on water salinity, bottom type and other water
conditions.
Specifi cations subject to change without notice.
