Adjusting or Changing Harness Straps (fig. a):
Harness straps must be through slots at or below
shoulders.
• Press Tab to release metal Rod and lift Rod
out of side Pockets.
• Slide metal Rod out of Loops of harness
straps.
• If necessary to change slots, pull harness
strap out of current Slots and thread through
desired Slots.
IMPORTANT: Straps MUST be through
matching Slots of seat pad and car seat.
• Select Loops that provide proper snugness.
Make sure the Rod is threaded through the
same loop position on both straps.
• Replace metal Rod into side Pockets and
slide Rod down below Tab.
Make sure Tab holds metal Rod secure ly.
OPERATIONS and ADJUSTMENTS
(continued)
20
Changing Crotch Strap Positions (fig. b):
Buckle tongue must be in slot closest to but
not under child.
• From bottom of car seat, remove crotch
strap Clip.
• From top of car seat, rethread crotch strap
through desired Opening.
• Re-attach crotch strap Clip exactly as
shown.
Pull on buckle to make sure it is held
securely
.
5 4
