SEAT PAD ASSEMBLY
(continued)
❃
Harness Assembly
Thread each end of harness strap from
back to front through slot in tongues (fig. l).
DO NOT twist harness strap.
Thread each end of harness strap through
chest clip.
Chest clip MUST be re-threaded exactly
as shown. (fig. m)
Thread each end of harness strap through
matching slots of seat pad and car
seat (fig. n).
Read instruction manual for proper
harness strap adjustments.
Adjust harness strap length by inserting
metal rod into loops that will position
harness strap for proper snugness (fig. o).
Make sure the ROD is threaded through
the same loop position on both sides.
Replace metal rod into side slots and slide
metal rod down below tab (fig. p).
Make sure tab holds metal rod securely.
Only use metal rod supplied by
Graco or child will not be restrained.
WARNING
1
2
3
4
5
