4 GXP21xx/GXP14xx/GXV31xx Configuration
Grandstream GXP21xx/GXP14xx/GXV31xx can be configured via web GUI as well as via
the Configuration File through TFTP or HTTP/HTTPS.
The GXP21xx/GXP14xx/GXV31xx accepts configuration files in XML format in addition to
the legacy proprietary binary format.
When Grandstream device boots up or reboots, it issues a request for a configuration file
named “cfgMAC.xml”, where “MAC” is the MAC address of the device, for example
“cfg000b820102ab.xml”. The configuration file name should be in lower case.
The following examples describe how to set the parameters using a configuration file. The
GXP21xx/GXP14xx/GXV31xx should be configured to load the configuration file each time
it resets or re-synchronizes. For detailed information on automated provisioning, see the
GXP21xx/GXP14xx/GXV31xx User Manual
[1] and the Grandstream XML Provisioning
Guide [6] .
The capabilities of the GXP21xx/GXP14xx/GXV31xx have been verified for use with
BroadWorks based on the settings described in the following table. For more information
on the meaning, purpose, and applicability of the individual configuration items see the
GXP21xx/GXP14xx/GXV31xx Configuration Tool and Template
[7] .
Configuration Files
Files Provided by Partner Level Description
cfgMAC.xml
Example: cfg000b82000000.xml
System and
Subscriber Contains configurable parameters that
apply to an individual device in a
deployment.
Configuration Template
Example:
gxp21xx__gxp1450_config_1.0.1.39.txt
gxv3140_config_1.0.7.3.txt
gxv3175_config_1.0.1.4.txt
System and
Subscriber Contains a complete list of
configurable parameters that apply to
an individual device in a deployment.
