GRANDSTREAM GXP21XX/GXV3140/GXV3175 SERIES PHONES 20-BD5320-00
© 2011 GRANDSTREAM PAGE 27 OF 45
Example Auto Configuration Options settings:
Figure 4 Auto Configuration Options Settings
5.2.2.2.1.2 Configure Device Management Options
Modify the device profile type Device Management Options as directed in the table below.
Note that these are common settings that apply to all devices enabled for Device
Management.
Parameters not identified in the following table can normally be left as defaults.
Parameter Value Description/Notes
Device Configuration
Tags Use Default System Tag Set and
Tag Set
Select the device tag set created in
section
5.2.1.2 .
Allow Identity/Device
Profiles to Configure
Custom Tags checked Optional
Allow Groups to
Configure Custom
Tags checked Optional
Device Access
Protocol http
Device Access FQDN Address>
Example: xsp.iop1.broadworks.net
Set to the XSP cluster FQDN if
using an XSP farm. Otherwise, set
to the individual XSP FQDN or IP
address.
Device Access Port
Example: 80
Should be set to 80.
Device Access
Context Name dms This does not need to be defined.
BroadWorks defaults to the system-
defined value.
Device Access URI
Example: Grandstream_GXV3175
This defines the directory the XSP
uses to access the configuration
files.
