2-11

Installation

Rack Setup

The Quad-Z 215 Liquid Handler is equipped to

locate Code 20-, 30-, 200-, and 500-series racks. See

for a list of racks available for the liquid

handler.

Depending on the racks you’re using, refer to the

appropriate procedures on the following pages.

Code 200-Series and
Code 500-Series Racks

If all your racks are Code 200-series or Code 500-

series racks, place them directly onto the locator

plate:

1 Orient the rack so that the code number (for

example, 200) is facing forward.

2 Fit the rack on the locator plate so that the slots

and holes on the underside of the rack align

with the pins on the locator plate.
