Pump assembly – parts – Graco Inc. Hydra-Clean 2800 User Manual
Page 21
21
824–001
Pump Assembly – Parts
USE ONLY GENUINE GRACO PARTS AND ACCESSORIES
Model
804–544
REF
PART
NO.
NO.
DESCRIPTION
QTY
1
CRANKCASE
1
2
801-484
PLUG
2
3
802-344
O-RING
1
4
PROTECTOR
1
5
KIT 83
SEAL, Oil
6
PLUG
1
7
MANIFOLD
1
8
WASHER
8
9
SCREW
8
10
KIT 1
O-RING
11
KIT 1
SEAT, Valve
12
KIT 1
PLATE, Valve
13
KIT 1
SPRING
14
KIT 1
CAGE, Valve
15
KIT 84
O-RING
16
KIT 84
CAP, Valve
17
KIT 1
VALVE ASSEMBLY
18
KIT 96,97 RING, Head
19
KIT 96,97 PACKING
20
KIT 96
RETAINER, Packing
21
KIT 96,97 O-RING
22
KIT 96,97 O-RING
23
802-345
GAUGE, Sight
1
24
BEARING
1
REF
PART
NO.
NO.
DESCRIPTION
QTY
25
801-659
DIPSTICK
1
26
NUT
3
27
WASHER
3
28
PLUNGER
3
29
803-918
O-RING
3
30
803-919
RING, Back Up
3
31
WASHER, Flinger
3
32
PIN, Connecting Rod
3
33
COVER, Crankcase
1
34
SCREW
4
35
804-015
GASKET, Cover
1
36
END, Connecting Rod
3
37
ROD, Connecting
3
49
SCREW
4
50
801-652
WASHER
4
51
FLANGE
1
52
SCREW
4
53
WASHER
4
54
SPACER
1
55
803-268
O-RING
1
56
804-018
SEAL, Oil
1
57
RING, Snap
1
58
BEARING
1
59
CRANKSHAFT
1
Kit
No.
Repair Kit
Part No.
Ref
No.
Description
Qty.
1
801-472
Valve
Assembly
10
11
12
13
14
or
17*
O-RING
SEAT, Valve
PLATE, Valve
SPRING
CAGE, Valve
VALVE ASSEMBLY
6
6
6
6
6
6
83
804-033
Oil Seal
5
SEAL, Oil
3
84
804-034
Valve Cap
15
16
O-RING
CAP, Valve
6
6
96
804-036
Packing
Assembly
18
19
20
21
22
RING, Head
PACKING
RETAINER,
Packing
O-RING
O-RING
1
1
1
1
1
97
804-037
Packing
18
19
21
22
RING, Head
PACKING
O-RING
O-RING
3
3
3
3
* Item 17 consists of items 10 through 14.
See Pump Assembly illustration on previous page.
