Page 40
-38-
g0484 gear head Mill/drill
Head parts List
REF PART #
DESCRIPTION
REF PART #
DESCRIPTION
201
P0484201
MOTOR 1-1/2HP 220V/60HZ/1-PH
244
P0484244
PIN
201-1 P0484201-1 MOTOR JUNCTION BOX COVER
245
PSB05M
CAP SCREW M8-1.25 X 50
201-2 P0484201-2 MOTOR JUNCTION BOX
246
P0484246
ELECTRIC BOX
201-3 P0484201-3 CAPACITOR CD60 150MFD/250VAC
246-1 P0484246-1 LIFT MOTOR CONTACTOR KM2
201-4 P0484201-4 CAPACITOR CBB60 20MFD/450VAC
246-2 P0484246-2 LIFT MOTOR CONTACTOR KM1
201-5 P0484201-5 TERMINAL BLOCK
246-3 P0484246-3 LIFT MOTOR UP BUTTON
201-6 P0484201-6 MOTOR FAN COVER
246-4 P0484246-4 LIFT MOTOR DOWN BUTTON
201-7 P0484201-7 MOTOR FAN
246-5 P0484246-5 EMERGENCY STOP BUTTON
202
PSB64M
CAP SCREW M10-1.5 X 25
246-6 P0484246-6 MASTER JUNCTION TERMINAL BLOCK
203
PK74M
KEY 6 X 6 X 35
246-7 P0484246-7 TRANSFORMER
204
P0484204
HEAD BODY COVER
246-8 P0484246-8 SPINDLE MOTOR ROTARY SWITCH
205
P0484205
OIL CAP
246-9 P0484246-9 MASTER POWER SWITCH
206
P0484206
OIL SEAL
247
P0484247
PRESSURE RELIEF HOSE
207
PR38M
INT RETAINING RING 62MM
248
P0484248
KNURLED KNOB
208
P6007
BALL BEARING 6007ZZ
249
PLW03M
LOCK WASHER 6MM
209
P0484209
MOTOR SHAFT
250
PW01M
FLAT WASHER 8MM
210
PK42M
KEY 6 X 6 X 30
251
P0484251
SPRING CAP
211
P0484211
GEAR
252
P0484252
COIL SPRING
212
P6003
BALL BEARING 6003ZZ
253
PFH05M
FLAT HD SCR M5-.8 X 12
213
P0484213
BEARING BRACKET
254
P0484254
SPRING BASE
214
P0484214
STOPPLE
255
P0484255
PIN
215
P0484215
GEAR
256
PSS73M
SET SCREW M10-1.5 X 30
216
P0484216
GEAR
257
PN02M
HEX NUT M10-1.5
217
P0484217
KEY 6 X 6 X14
258
P0484258
HANDLE ROD
218
P0484218
KEY 5 X 5 X 60
259
P0484259
BUSHING
219
P0484219
SHAFT
260
P0484260
FACE PLATE
220
P0484220
STEEL BALL 8MM
261
PSS20M
SET SCREW M8-1.25 X 8
221
P0484221
COMPRESSION SPRING
262
P0484262
SPEED LEVER
222
PR07M
EXT RETAINING RING 18MM
263
P0484263
OIL SEAL
223
P6202
BALL BEARING 6202ZZ
264
PR03M
EXT RETAINING RING 12MM
224
PR21M
INT RETAINING RING 35MM
265
P0484265
LEVER SHAFT ( LEFT )
225
P0484225
O-SEAL RING
266
PN01M
HEX NUT M6-1
226
P0484226
CAP
267
PSS04M
SET SCREW M6-1 X 12
227
P0484227
GEAR
268
P0484268
LEVER ( LEFT )
228
P0484228
SHAFT
269
P0484269
PIN
229
PK36M
KEY 5 X 5 X 50
270
P0484270
LEVER BRACKET
230
P0484230
KEY 6 X 6 X 75
271
P0484271
PIN
231
P0484231
GEAR
272
P0484272
LEVER ( RIGHT )
232
P0484232
GEAR
273
P0484273
LEVER SHAFT ( RIGHT )
233
P0484233
GEAR
274
PS17M
PHLP HD SCR M4-.7 X 6
234
P0484234
AIRTIGHT RING
275
P0484275
SPECIAL NUT
235
P0484235
AIRTIGHT BASE
276
P0484276
HEAD BODY
236
PS05M
PHLP HD SCR M5-.8 X 8
277
P0484277
BUSHING
237
P0484237
OIL SEAL
278
P0484278
OIL COVER
238
P0484238
GEAR
279
P0484279
SIGHT GLASS
239
P0484239
GEAR
280
P0484280
SCALE
240
P0484240
SEPARATING RING
281
PS05M
PHLP HD SCR M5-.8 X 8
241
PR12M
EXT RETAINING RING 35MM
282
P0484282
PIN
242
P0484242
ARBOR BOLT COVER
283
P0484283
KNOB
243
PSB33M
CAP SCREW M5-.8 X 12
284
P0484284
SUPPORT
