-16-
g0484 gear head Mill/drill
Loose hair and cloth-
ing could get caught in
machinery and cause seri-
ous personal injury. Keep
loose clothing and long
hair away from moving
machinery.
Operation Safety
SEcTION 4: OpERATIONS
NOTICE
If you have never used this type of machine
or equipment before, WE STRONGLy REc-
OMMEND that you read books, trade maga-
zines, or get formal training before begin-
ning any projects. Regardless of the con-
tent in this section, Grizzly Industrial will
not be held liable for accidents caused by
lack of training.
control panel
A. power Lamp: glows when power is flowing
to the machine.
b. Headstock up button: Controls the head-
stock motor so the headstock is powerfed
upwards.
c. Headstock Down button: Controls the
headstock motor so the headstock is power-
fed downwards.
D. Emergency Stop button: stops the mill/
drill. rotate the button clockwise until it pops
back out to reset it.
E. Master power Switch: toggles main power
to the machine.
f. Spindle Rotation Dial: Changes spindle
rotation direction for milling/drilling operations.
spindle rotation must always be stopped
before making direction changes.
figure 11. Control panel.
A
E
d
C
F
B
Damage to your eyes and lungs could result
from using this machine without proper pro-
tective gear. Always wear safety glasses and
a respirator when operating this machine.
