-24-
Model g0533 (Mfg. since 3/11)
REF PART # DESCRIPTION REF PART # DESCRIPTION
1AV2 P0533001AV2 BLOWER HOUSING ASSY V2.03.11 11-20 P0533011-20 SIDE FILTER CASE SUPPORT
1V2 P0533001V2 BLOWER HOUSING V2.03.11 11-21 PHTEK34 TAP SCREW 1/4 X 1/2
1-1V2 P0533001-1V2 IMPELLER 12" V2.03.11 11-22 PN05 HEX NUT 1/4-20
1-2 PB21 HEX BOLT 3/8-16 X 3/4 11-23 PW06 FLAT WASHER 1/4 IN
1-3V2 P0533001-3V2 INTAKE PORT V2.03.11 11-24 P0533011-24 SWITCH BASE
1-4 PW07 FLAT WASHER 5/16 11-25 PHTEK39M TAP SCREW M4 X 12
1-5 PB07 HEX BOLT 5/16-18 X 3/4 11-26 P0533011-26 CURTAIN BRACE LEFT
2 PB03 HEX BOLT 5/16-18 X 1 11-27 PB07 HEX BOLT 5/16-18 X 3/4
3 PW07 FLAT WASHER 5/16 11-28 P0533011-28 CURTAIN BRACE RIGHT
4V2 P0533004V2 MOTOR 3HP 230V 1PH T3C V2.03.11 12 P0533012 HOOK 3/8-16
4-1 PB52 HEX BOLT 1/2-13 X 1 12-1 PW02 FLAT WASHER 3/8
4-2 PTLW04 EXT TOOTH WASHER 1/2 12-2 PN08 HEX NUT 3/8-16
4-3 PB18 HEX BOLT 3/8-16 X 1 13 P0533013 FILTER CASE
4-4 PW02 FLAT WASHER 3/8 14 P0533014 5 MICRON THIRD STAGE FILTER
4-5 PN08 HEX NUT 3/8-16 15 P0533015 CONNECTOR BAR
5 P0533005 AIR FILTER INDICATOR 16 PN05 HEX NUT 1/4-20
5-1 PHTEK39M TAP SCREW M4 X 12 17 PW06 FLAT WASHER 1/4 IN
5-2 P0533005-2 CLIP PLASTIC 18 PFH04 FLAT HD SCR 1/4-20 X 5/8
5-3 P0533005-3 TUBING 19 P0533019 RIGHT STEEL CURTAIN
5-4 P0533005-4 TUBING CONNECTOR FITTING 20 PN05 HEX NUT 1/4-20
5-5 P0533005-5 RED GAUGE OIL 21 PW06 FLAT WASHER 1/4 IN
5-6 P0533005-6 RED ARROW 22 PN05 HEX NUT 1/4-20
5-7 P0533005-7 GREEN ARROW 23 PW06 FLAT WASHER 1/4 IN
6 PHTEK46M TAP SCREW M4 X 45 24 PFH04 FLAT HD SCR 1/4-20 X 5/8
7 P0533007 OUTLET 12" 25 PFH04 FLAT HD SCR 1/4-20 X 5/8
8 PB03 HEX BOLT 5/16-18 X 1 26 P0533026 WORK TABLE
9 PW07 FLAT WASHER 5/16 26-1 P0533026-1 WORK TABLE LEG
10 PN02 HEX NUT 5/16-18 26-2 PB06 HEX BOLT 5/16-18 X 2
11 P0533011 COVER TOP 26-3 PW07 FLAT WASHER 5/16
11-1 P0533011-1 BACK COVER 26-4 PN02 HEX NUT 5/16-18
11-2 PB21 HEX BOLT 3/8-16 X 3/4 27 P0533027 LEG CUSHION 3/8"
11-3 PW02 FLAT WASHER 3/8 27-1 PW02 FLAT WASHER 3/8
11-4 PN08 HEX NUT 3/8-16 27-2 PB60 HEX BOLT 3/8-16 X 3
11-5 PN08 HEX NUT 3/8-16 27-3 PN08 HEX NUT 3/8-16
11-6 PW02 FLAT WASHER 3/8 28 P0533028 CURTAIN TOP STEEL
11-7 PB21 HEX BOLT 3/8-16 X 3/4 28-1 P0533028-1 CURTAIN TOP SMALL
11-8 P0533011-8 COVER RIGHT 28-2 PHTEK34 TAP SCREW 1/4 X 1/2
11-9 P0533011-9 FILTER CASE BRACE 28-3 PW06 FLAT WASHER 1/4 IN
11-10 PN02 HEX NUT 5/16-18 28-4 PN05 HEX NUT 1/4-20
11-11 PW07 FLAT WASHER 5/16 29 H5838 10 MICRON SECOND STAGE FILTER
11-12 PB07 HEX BOLT 5/16-18 X 3/4 30 H5837 30 MICRON FIRST STAGE FILTER
11-13 PB21 HEX BOLT 3/8-16 X 3/4 31 P0533031 LEFT STEEL CURTAIN
11-14 PW02 FLAT WASHER 3/8 32 P0533032 SUPPORT BAR
11-15 PN08 HEX NUT 3/8-16 33 P0533033 OUTLET GASKET
11-16 P0533011-16 FILTER CASE BASE 34 P0533034 INLET GASKET
11-17 P0533011-17 COVER LEFT 49 P0533049 DOOR LATCH PIN
11-18 P0533011-18 TOP FILTER CASE SUPPORT 49-1 P0533049-1 COMPRESSION SPRING
11-19 P0533011-19 FILTER CASE SUPPORT MIDDLE 49-2 P0533049-2 SPRING RETAINER
Main Parts List
