6. With new filters installed, turn the spray booth
ON, observe the rise in the reading, and mark
with the supplied green arrow as shown in the
example in
figure 19.
7. Multiply the reading from Step 6 times 2 (2x)
and mark with the supplied red arrow ( figure
20). this is the dirty filter indicator mark.
When the fluid reaches the red arrow, install
new filters.
Note: Always make sure the fluid level is at
zero before using the spray booth each time.
Also, check the fluid level on a regular basis
and re-fill as needed.
figure 20. dirty filter mark example.
dirty Filter
indicator
Mark
figure 19. new filter installation mark example.
new Filter
indicator
Mark
