Know your product
1. Trigger switch
2. On / off switch
3. Lock-on button
4. Scrolling control knob
5. Pendulum lever (scrolling lock)
6. Blade guard
7. Blade guide
8. Variable speed dial
9. Removable handle
10. Handle release catch
11. Handle locating pin
(not visible)
12. Combined laser light /
LED switch
13. Laser aperture
14. Dust extraction port
15. Dust extraction adaptor
16. Cutting angle scale
17. Tool free blade
change control
18. Shoe plate
19. Bevel locating pin (not visible)
20. Parallel guide
21. Parallel guide locking knob
22. Jigsaw blades
23. Anti splintering insert
24. Blade storage area (x 2)
25. Blade storage release tab (x 2)
26. Hex key
22 15 20
23 18 5 16 2 14 24 25 15
13
6
17
21
7
12 4 1 3 9 10
8
26 23
