nüvifone A50 Quick Start Manual
5
Mounting Your Device
WarninG
This product contains a lithium‑ion battery.
To prevent the possibility of personal
injury or product damage caused by battery
exposure to extreme heat, remove the
device from the vehicle when exiting or
store it out of direct sunlight.
Lever
Suction
cup arm
Cradle
Vehicle power cable
1. Plug the vehicle power cable into the
power connector on the back of the
cradle.
2. Remove the clear plastic from the
suction cup.
3. Clean and dry your windshield and the
suction cup with a lint‑free cloth.
4. Place the suction cup on the windshield.
5. Flip the lever back, toward the
windshield.
6. Snap the cradle onto the suction cup
arm.
7. Fit the gold contacts on the left side of
your device into the cradle.
8. Tilt the device back until it snaps into
the cradle.
9. Plug the other end of the vehicle power
cable into a power outlet in your
vehicle.
