Secure Perfect 6.1.1 User Manual 197
Micro
Device Menu
The Micro option opens the Micro Form that allows you to identify and configure micros.
Micro/5-PX or Micro/PX-2000 Records Generation
When you select a micro type on the Micro Definition tab of the Micro Form, a Power/Comm board is
automatically added to the Configuration column on the Micro Configuration tab of the Micro Form. As a
result, certain additional records are created:
Alarm Records:
• Tamper
• Power
• Lost Badge Alarm
• Invalid Badge
• Host Comm Alarm
• 8RP Reminder: The Micro/PX-2000 supports 4 readers.
• 16DO Reminder: The Micro/PX-2000 supports 8 DO points.
• 20DI Reminder: The Micro/PX-2000 supports 11 DI points.
Micro/PX-2000 boards shipped after November 1, 2003, support the 11th DI as a low-battery
alarm for the micro.
None of these alarms are monitored. If you want them to display on the Alarm Monitor when the alarm is
triggered, you will need to go to the Alarm Form, Alarm Tab and enable Monitor in the Settings section.
In addition, all alarms are automatically assigned to Alarm Group 0. You can change the Alarm Group on
the Alarm Group Form.
Digital Input Records:
• Tamper
• Power
Sixteen (16) Alarm Group Records:
As mentioned above, all alarms are automatically assigned to Alarm Group 0. You can change this on the
Alarm Group Form.
Micro Assignment Dialog Box
This window displays when you click Edit, allowing you to select and assign micro association for this
form. Only micros in the operators’
facilities are available for assignment by this operator.
• Select, and then click the right arrow to assign an available micro.
• Select, and then click the left arrow to unassign a micro.
