M6 Washer (36)

M10 x 50mm Screw (27)

M8 Curve Washer (39)

M8 Washer (37)

M10 Nylon Locknut (44)

M8 x 19mm Screw (38)

M6 x 38mm Screw (29)

M4 x 25mm Screw (45)

M4 x 20mm Screw (42)

M10 x 62mm Bolt (24)

M6 x 70mm Screw (35)

M10 x 100mm Bolt (43)

M10 x 127mm Bolt (32)

M10 x 53mm Bolt (30)

M10 x 87mm Bolt (47)

M8 x 15mm Screw (28)

M10 x 90mm Bolt (46)

M8 x 25mm Shoulder Screw (41)

PART IDENTIFICATION CHART

See the drawings below to identify small parts used in assembly. The number in parentheses by each drawing is
the key number of the part, from the PART LIST in the center of this manual.

Note: Some small parts may

have been pre-attached. If a part is not in the parts bag, check to see if it has been pre-attached.
