-60-
G0460/G0461 12" Sliding Table Saw
REF PART # DESCRIPTION
9 PSB01M CAP SCREW M6-1 X 16
20 PSB13M CAP SCREW M8-1.25 X 30
22 PN03M HEX NUT M8-1.25
25 PN02M HEX NUT M10-1.5
29 PN01M HEX NUT M6-1
37 PSB03M CAP SCREW M5-.8 X 8
82 P0460082 CROSSCUT TABLE
84 P0588084 SUPPORT ADJUSTMENT BLOCK
85 PSB04M CAP SCREW M6-1 X 10
86 PSS09M SET SCREW M8-1.25 X 20
87 P0460087 SCALE LABEL (RIGHT)
89 P0588089 SLIDING SURFACE PLATE
90 P0588090 CROSSCUT TABLE LOCK PLATE
91 PW04M FLAT WASHER 10MM
92 P0588092 ADJUST HANDLE M10-1.5
93 P0460093 SWING ARM
93A P0460093A SWING ARM ATTACHMENT
94A P0588094A ECCENTRIC ROLLER
95A P6901 BALL BEARING 6901
96A P0588096A ECCENTRIC SHAFT
97 P0588097 ROTATE ARBOR SUPPORT
98 P0588098 MAGNET
99 P0588099 MAGNET BASE
100 PFH30M FLAT HD SCR M5-.8 X 8
101 P0588101 NYLON SCREW M12-1.75 X 12
102 P0588102 SWING ARM END
103 P0588103 BRUSH
104 PSB117M BUTTON HD CAP SCR M5-.8 X 8
105 P0588105 SWING ARM END
106 P0460106 EXTENSION SWING ARM
107 P0588107 SWING ARM ADJUST SCREW M20-2.5
108 PN28M HEX NUT M20-2.5
117 PW01M FLAT WASHER 8MM
118 PLN04M LOCK NUT M8-1.25
188 P0460188 HEX BOLT M8-1.25 X 100
189 P0588189 STOP BLOCK
262 P6204 BALL BEARING 6204ZZ
265 P0588265 SWING ARM SHAFT
Crosscut Table Parts List
