G0460/G0461 12" Sliding Table Saw
-3-
Overall Dimensions:
Overall Size (with Cross Slide Fence and Sliding Table Extended) .....................................................132" W x 136" D x 48" H
Table Height ............................................................................................................................................................................ 36"
Table Size (w/Extension Wings) ............................................................................................................................65" W x 59" D
Sliding Table Size ............................................................................................................................................. 13¾" W x 59" D
Machine Net Weight .........................................................................................................................................................885 lbs.
Machine Shipping Weight ..............................................................................................................................................1163 lbs.
Crate Size ...........................................................................................................................................70 1 ⁄
2
" W x 42" D x 44 1 ⁄
2
" H
Base Footprint (w/Extension Leg) .......................................................................................................................... 45" W x 73" L
Capacities:
Main Blade Diameter ................................................................................................................................................12" (305mm)
Scoring Blade Diameter ............................................................................................................................................3 1 ⁄
8
" (80mm)
Maximum Depth of Cut at 90° ................................................................................................................................................ 3 3 ⁄
4
"
Maximum Depth of Cut at 45° ................................................................................................................................................ 2 5 ⁄
8
"
Blade Tilt .............................................................................................................................................................................0–45°
Ripping Width (w/Standard Rip Fence) ................................................................................................................................ 44 1 ⁄
2
"
Cross Cut Width (Maximum Distance from Left of Blade to Crosscut Fence Stop) ............................................................... 72"
Cross Cut Length (Maximum Distance in Front of Blade) ...................................................................................................... 59"
Maximum Miter Cut Width at 45° ............................................................................................................................................ 51"
Construction:
Sliding Table ................................................................................................................................................................ Aluminum
Machine Frame .................................................................................................................................................................... Steel
Fence ............................................................................................................................................................Extruded Aluminum
Rails ..................................................................................................................................................................... Chromed Steel
Trunnions .......................................................................................................................................................................Cast Iron
Motor:
G0461 Motor ............................................................................................7 1 ⁄
2
HP, 220/440V (Prewired 220V), 20/10A, 3-Phase
G0460 Motor ..............................................................................................................................5 HP, 220V, 22A, Single-Phase
Motor RPM .................................................................................................................................................................. 3450 RPM
Main Blade Arbor ...................................................................................................................................................................... 1"
Main Blade Arbor Speed ............................................................................................................................................. 4900 RPM
Scoring Blade Arbor ........................................................................................................................................................... 20mm
Scoring Arbor Speed ................................................................................................................................................... 9000 RPM
Ball Bearings ............................................................................................................................................. Shielded & Lubricated
Power Transfer ..............................................................................................................................................................Belt Drive
Switch ..........................................................................................................................Magnetic w/Thermal Overload Protection
Features:
......................................................................................................................................................Blade Guard w/2½" Dust Port
......................................................................................................................................................................... 5" Main Dust Port
...................................................................................................................................................... Adjustable Scoring Knife Kerf
................................................................................................................................................................ Adjustable Riving Knife
............................................................................................................................Micro Adjustable, Single Lever Locking Fence
MODEL G0460/G0461 12" SLIDING TABLE SAW
Customer Service #: (570) 546-9663 • To Order Call: (800) 523-4777 • Fax #: (800) 438-5901
MACHINE DATA
SHEET
Specifications, while deemed accurate, are not guaranteed.
