Ngine – Gravely 927062 - RM1232 User Manual
Page 5
5
E
NGINE
Model 927062
Item
Part No.
Qty.
Description
1
52710400
1
Group, Engine 12HP Intek
2
07240600
1
Belt, Poly V (Hydro)
3
06601800
1
Key, Straight .25 x 1.75 x .25
4
02764900
1
Pulley Drive (Hydro)
5
02768100
1
Belt, PTO
6
06443500
1
Washer, Flat Steel .463 x 1.375 x .25
7
06309300
1
Washer, Locking .44 x .109 Regular
8
05967500
1
Bolt, Hex .44-20 x 1.75 Grade 5
9
06535800
6
Nut, Locking Top Flange .38-16
10
03622900
2
Shoulder Stud
11
06435700
2
Washer, Flat Steel .38 x .875 x .083
12
06944800
2
Clip, Spring
13
02771900
4
Bushing, .625 x .50 x .75
14
05958000
2
Bolt, Hex .38-16 x 1.25 Grade 5
15
06544500
1
Nut, Locking Top Flange .38-16
16
08311000
1
Spring, Tension .08 x .687 x 5.16
17
02773100
1
Bracket, PTO Idler
18
07318400
1
Sheave 3.25 x 1.25
19
02773000
1
Bracket, Poly-V Idler
20
07326500
1
Idler, Flat 1.875 O.D. x .75
21
08537800
1
Spring, Extension
PA0320
2
4
3
5
6
7
8
9
10
11
12
13
14
15
15
9
11
10
14
16
17
13
15
12
18
19
20
21
