Gravely 927062 - RM1232 User Manual
Page 3
3
M
ODELS
927062 (1232)
12 H.P. 32” Hydro
Serial No. 000101 and up
T
ABLE
O
F
C
ONTENTS
D
ECALS
Decals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
F
RAME
, E
NGINE
, C
ONTROLS
AND
F
UEL
Frame, Hood and Seat . . . . . . . . . . . . . . . . . . . . . . . . 5
Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Steering and Front Wheels. . . . . . . . . . . . . . . . . . . . . 7
Rear Wheels and Hydro Drive . . . . . . . . . . . . . . . . . . 9
Brake System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Gas Tanks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
E
LECTRICAL
S
YSTEMS
Electrical System . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Continuity Diagram. . . . . . . . . . . . . . . . . . . . . . . . . . 15
Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
D
ECKS
Decks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Deck Lift . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
D
ECALS
Item Part No.
Qty.
Description
1
05301900
2
Decal, Gravely ZT
2
05305000
1
Decal, Trailer Hitch
3
05301600
1
Decal, Rear Engine Rider Warning
4
05304800
1
Decal, Throttle
5
07742300
1
Decal, Warning
6
07731400
2
Decal, Mower Pan Danger
7
05303600
2
Decal, Rear Engine Rider Gravely 1232
8
05223900
1
Decal, Gravely
9
07757500
1
Decal, Parking Brake Lever
10
07719800
1
Decal, Ignition
11
05305600
1
Decal, Transmission Disconnect
12
05305100
1
Decal, American Flag
13
07754100
1
Decal, Hot Surface
DANGER / PELIGRO
07731400D
077541
WARNING/AVERTISSEMENT/ADVERTENCIA
Do not operate mower
unless guards are in
operating position or
bagger is attached.
Ne jamais utiliser
la tondeuse sans
protecteur sur le
canal d'ejection ou
sans le bac monte.
No operar segadora a
menos que las defensas
esten en posicion de
operacion o el
recogedor este fijo.
07742300B
05304800A
07719
800B
05305600
PA0290
