14
C
ONTINUITY
D
IAGRAM
Model 927062
Solenoid
NOT ENERGIZED
ENERGIZED
The diagrams below show the various states of connection for electrical components.
The solid lines on switches show continuity.
NOTE: All switches are viewed from the rear.
PTO Switch
Seat Switch
Neutral Switch
1
2
BUTTON DOWN
1
2
BUTTON UP
Relay
3
9
4
7
1
DISENGAGED
(down position)
3
9
4
7
1
ENGAGED
(up position)
1
OPERATOR
OFF SEAT
2
1
OPERATOR
ON SEAT
2
87
87A
86
85
30
NOT ENERGIZED
87
87A
86
85
30
ENERGIZED
OFF
M
G
S2
B
S1
A
RUN
M
G
S2
B
S1
A
START
M
G
S2
B
S1
A
Key Switch
(01563700)
OFF
ON
Light Switch
(03656800)
Parking Brake Switch
(08828300)
1
2
PARKING BRAKE ON
1
2
PARKING BRAKE OFF
(03042800)
(01545600)
(03171600)
(03095700)
(03679000)
PA0260
