G0605X/G0606X Extreme Series 12" Table Saw
-15-
Machine Inventory
The following components are included with each
G0605X/G0606X. After all the parts have been
removed from their packaging, you should have:
Box Contents (Figures 3 & 4): Qty
A. Table Saw Unit ........................................... 1
B. Splitter/Guard Assembly ............................. 1
C. Riving Knife ................................................ 1
D. Miter Gauge Handle ................................... 1
E. Miter Gauge ................................................ 1
F. Handwheel Handles ................................... 2
G. Fence Resting Brackets ............................. 2
H. Arbor Wrenches ........................................ 2
I. Arbor Extension 5 ⁄
8
"-18 x 1 1 ⁄
4
" ..................... 1
J. Arbor Nut 5 ⁄
8
-18 .......................................... 1
K. Arbor Flange 5 ⁄
8
" ........................................ 1
Hardware and Tools (Not Shown): Qty
• Flat Washer 8mm (Miter Gauge) ............... 1
• Flange Bolts M8-1.25 x 12 (Fence) ............ 2
• Flange Bolts M8-1.25 x 12 (Switch) ........... 2
• Open-End Wrenches
8 x 10, 11 x 13, 14 x 17 ....................1 Each
• Hex Wrenches 4, 5, 6mm .................1 Each
• Screwdriver, Phillips/Flat ............................ 1
• Safety Pin (Switch) ..................................... 1
• Flat Head Screw M5-8 x 20 ....................... 1
Figure 3. G0606X table saw unit.
A
Fence Inventory
Box Contents: (Figure 5) Qty
A. Fence ......................................................... 1
B. Fence Handle ............................................. 1
Figure 5. Fence components.
A
B
Fence Rail Inventory
Box Contents: (Figure 6) Qty
A. Fence Tube (91 3 /
8
" Long) ........................... 1
B. Front Rail (91 3 /
8
" Long) ............................... 1
C. Rear Rail (79" Long) ................................... 1
Figure 6. Fence rail components.
A
B
C Figure 4. Main components.
B
E
D
F
H G
C
I
J K
