Identification – Grizzly G1005Z User Manual
Page 7
G1005Z Mill/Drill
-5-
A. Junction Box
B. Headstock Height Crank
C. Return Spring Assembly
D. Quill Lock
E. Depth Stop
F. ON/OFF Swtich
G. Micro-Downfeed Handwheel
H. Motor Pivot Lock
I. Downfeed Handles
J. Pinion Hub Lock Knob
K. Table Handwheels
L. Longitudinal Stops
M. Gib Screws
N. Longitudinal Locks
Identification
Figure 1. G1005Z Identification.
B
C
D
E
F
H
I
J
K
L
M
N
G
A
