-12-
G1005Z Mill/Drill
Inventory
After all the parts have been removed from the
shipping crate, you should have the following
items:
Main Components: (Figure 3)
Qty
A. Mill/Drill (not shown) ................................... 1
B. Downfeed Handle Knobs
1
⁄
2
"-12 ................. 3
C. Downfeed Handles
1
⁄
2
"-12 ........................... 3
D. Face Mill Arbor R8 ..................................... 1
E. Chuck Key .................................................. 1
F. Handwheels ................................................ 3
G. Face Mill 2
1
⁄
2
" ............................................. 1
H. Arbor R
8
⁄JT6 (installed, not shown) ............ 1
I. Handwheel Handles
3
⁄
8
-16 x
7
⁄
8
................... 4
J. Vise 3
1
⁄
2
" ..................................................... 1
K. Drill Chuck JT6
1
⁄
2
" ..................................... 1
Other Components and Hardware:
•
Cap Screw
3
⁄
8
-16 x 1 (mill arbor) ................ 1
•
Flat Washer
3
⁄
8
" (mill arbor) ........................ 1
•
Hex Wrench 4mm ...................................... 1
•
Hex Wrench 5mm ...................................... 1
Figure 3. G1005Z Inventory.
In the event that any nonproprietary parts are
missing (e.g. a nut or a washer), we would be
glad to replace them, or for the sake of expedi-
ency, replacements can be obtained at your local
hardware store.
NOTICE
Some hardware/fasteners on the inventory
list may arrive pre-installed on the machine.
Check these locations before assuming that
any items from the inventory list are miss-
ing.
B
C
D
E
F
G
I
J
K
