Section 8 — Exploded Views and Parts Lists
Air-cooled 11 kW Generators
Alternator & Pulleys – Drawing No. 0E4880
ITEM PART
NO. QTY. DESCRIPTION
1
0E0196A
1
FRAME,
MOUNTING
SS HSB
2
022129
7
WASHER LOCK M8-5/16
3
022145
8
WASHER FLAT 5/16-M8 ZINC
4
022259
4
NUT HEX 5/16-18 STEEL
5
0C7758
4
VIB MNT 1.5 X 1.38 X 5/16-18
6
0C3168
1
WASHER LOCK SPECIAL 5/16
7
0C2417
1
EARTH
STRAP
8
0E2424A
1
SKID, MOUNT ALTERNATOR
9
0E2425
1
SKID, MOUNT ENGINE
10
0E2421
1
MANIFOLD,
EXHAUST
11
0E1078A
1
GASKET, EXHAUST BASE
12
0E3020
1
BRACKET, FRAME EXTENSION
13
040976
4
SCREW SHC M8-1.25 X 20mm
14
056893
6
SCREW CRIMPTITE 10-24 X ½
15
023897
5
WASHER FLAT #10 ZINC
16
0E1078
1
GASKET, EXHAUST BASE
17
0C4138
2
GASKET,EXHAUST PORT
18
043116
3
SCREW HHC M6-1.0 X 12 G8.8
19
022097
3
WASHER LOCK M6-1/4
20
022473
3
WASHER FLAT 1/4-M6 ZINC
21
0C1752
1
FAN NYLON 8" DIA
22
0C1753B
1
PULLEY, ALTERNATOR 2200 RPM
23
075224D
1
PULLEY ENGINE 3600 RPM
24
073118
1
SCREW HHC 3/8"-24 X 2-1/4"
25
0E5984
1
DUCT, ALTERNATOR COVER
26
022131
1
WASHER FLAT 3/8-M10 ZINC
27
0C2824
6
SCREW TAP-R #10-32 X 9/16"
28
0A9827B
1
BLOWER
HOUSING
29
042633
1
SCREW HHC 3/8"-24 X 1"
30
022237
2
WASHER LOCK 3/8"
31
049451
1
WASHER FLAT 0.406" I.D. X 1.62" O.D.
32
0C1441
1
SET,BLOWER HOUSING GASKET
33
0C1112
1
BELT,V-RIB
4LX42.75"
34
083512
4
SCREW HHTT M8-1.2 X 16mm
35
039288
2
SCREW HHC M8-1.25 X 55mm
36
029459
2
TENSION SPRING
37
075215
2
WASHER, SPRING CENTER
38
052858
10
NUT LOCK FLANGE M8-1.25
39
075237
4
WASHER, SPRING CENTER
40
075242
4
SPRING, MOUNT
41
0A9202
2
SUPPORT, SLIDE
42
0A9918
4
SLIDE, NYLON
43
0E0575
3.5
FT
FOAM
SEALING STRIP 1"
44
0A9226
1
BEARING CARRIER LOWER
45
0E4748
4
STUD, STATOR
46
031971
1
BEARING
47
0E3233
1
ROTOR
48
073159
1
BEARING
49
0E3229
1
STATOR
50
0A9227
1
BEARING CARRIER UPPER
51
066386
1
ASSEMBLY, BRUSH HOLDER
52
066849
2
SCREW HHTT M5-0.8 x 16mm
53
056326
3.4'
TRIM
VINYL
BLACK
