Page 33
31
ITEM PART
NO. QTY. DESCRIPTION
1
0C5730A
1
ASSEMBLY, CRANKCASE RV
2
0E9843
1
SEAL, 38 I.D. CRANKCASE
3
090388
6
SCREW, HHTT M6-1.0 X 12mm
4
0C5372
1
ASSEMBLY, BREATHER
5
0C3005
1
GASKET, BREATHER COVER
6
0E3372A
1
SEPARATOR, OIL BREATHER
7
0D8067A
1
ASSEMBLY, HEAD #1
8
0C2981C
1
COVER,
ROCKER
9
071983
4
RETAINER,
PISTON PIN 20
10
0E2950
2
PISTON
11
021533
2
SET, PISTON RING 90mm
12
0E1466
2
PIN , PISTON
13
0D4041
1
ASSEMBLY, CAMSHAFT & GEAR
14
0C2977
1
GASKET, CRANK CASE
15
0C5943
1
SEAL, OIL PASSAGE
16
0E4357A
1
ASSEMBLY, CRANKSHAFT
17
082774
1
KEY, WOODRUFF 4 X 19D
18
0E3223
2
ASSEMBLY, CONNECTING ROD
19
0C2978
2
GASKET, HEAD
20
093873
3
WASHER, LOCK RIB M6
21
021374
3
SCREW, SHC M6-1.0 X 30mm
22
0C2994
1
SCREEN, OIL PICKUP
23
0C2997
1
COVER,
GEROTOR
24
0C2995
1
GEROTOR,
INNER
25
0C2996
1
GEROTOR,
OUTER
26
0C3011
2
COVER, OIL RELIEF
27
0C3009
2
SPRING, OIL RELIEF
28
0C3010
2
BALL, 1/2D OIL RELIEF
29
050873A
1
1/4" NPT PIPE PLUG
30
0E9842
1
SEAL, 42 I.D. CRANKSHAFT
31
0D9756
1
CONNECTOR, 3/8NPT TO INVTD FLR 3/8OD
32
0C5732A
1
ASSEMBLY SUMP WITH PLUG
33
0C3006
10
SCREW, HHFC M10-1.5 X 55mm
34
080318
8
SCREW HHFC M6-1.0 X 25mm
35
0C2982
1
COVER, ROCKER WITH OIL FILL
36
093064
1
ASSEMBLY, OIL FILL CAP
37
0C2979
2
GASKET, VALVE COVER
38
086515
8
KEEPER,
VALVE
SPRING
39
0D2274
4
RETAINER,
VALVE
SPRING
40
0D3867
4
SPRING, VALVE
41
078672
2
SEAL, VALVE STEM D7
42
0C5371
4
WASHER, VALVE SPRING
43
0D3998
4
NUT HEX M8-1.0 G8
44
072694
4
STUD ROCKER ARM PIVOT
45
0D5313
4
ROCKER
ARM
46
0E3273
1
SCREEN CRANKCASE BREATHER
47
0D6024
2
PLATE,
PUSH ROD GUIDE
48
0C2976
12
SCREW HHFC M8-1.25 X 65mm
49
0D8067B
1
ASSEMBLY, HEAD #2
50
0C2229
2
VALVE,
INTAKE
51
086516
2
VALVE,
EXHAUST
52
0D9853D
4
PUSHROD 147
53
083897
4
TAPPET,
SOLID
54
0E9323
1
STARTER MOTOR
55
022129
2
WASHER LOCK M8
56
061906
2
SCREW, HHC M8-1.25 X 85mm
Section 8 — Exploded Views and Parts Lists
Air-cooled 11 kW Generators
GT-990 Engine – Drawing No. 0F2000
