Generac Power Systems 004916-0 User Manual
Page 29
27
ITEM PART NO. QTY. DESCRIPTION
1
0E7325
4
HHFS, 1/4"-20 X 5/8" GRADE 5
4
0E6884
1
SEAL, ALTERNATOR SHAFT
5
0E4706A
1
SOUND BAFFLE INTAKE SCROLL
6
0D1131
1
GUARD,FAN
7
0E4706
1
SCROLL, INTAKE
8
0C2824
11 SCREW TAP-R #10-32 X 9/16"
9
039253
6
SCREW HHC M8-1.25 X 20
10
0A8250
1
SCREW HHC 3/8"-24 X 2" G8
11
0C3032
1
PLATE, FAN
12
0C3031
1
FAN FLYWHEEL NYLON
13
0E4683
1
FAN HUB WITH D-DRIVE
14
0E4378
1
ASSEMBLY, AIR INTAKE DUCT
15
0E6342
1
LATCH, ADJUSTABLE DRAW
16
0E7570
2
GAS SPRING
17
0E2874
37
SCREW TAP-R 1/4"-20 X 3/4"
18
0E4808
1
SUPPORT LOWER AIR INTAKE SEAL
19
083512
4
SCREW HHTT M8-1.2 X 16mm
20
0E4809A
1
BASE PAD
21
0E4377
1
BASE, ENCLOSURE
22
0C2937
1
BRACKET BATTERY HOLD DOWN
23
022129
12
WASHER LOCK M8-5/16"
24
0E1330A
1
GROMMET, 38.1mm CROSS SLIT WITH
HOLE
25
0E4805
1
BRACKET, BATTERY POSITION
26
0E4811
1
BRACKET, REGULATOR
27
0D3700
26
NUT FLANGE M6-1.0 NYLOK
28
0E5299D
1
FOAM, ENGINE SIDE PANEL ACOUSTIC
29
0E5299C
1
FOAM, ALTERNATOR SIDE PANEL
ACOUSTIC
30
0E5297
1
FOAM, ENGINE ENCLOUSURE BACK
31
0E4379
1
ENCLOSURE, POWER HEAD
32
0E5273
1
RAIL, ROOF STAY SUPPORT
33
0F0165
2
HINGE TYPE B WITH STUDS, PIN
34
0F0165A
1
HINGE TYPE B WITH STUDS, SOCKET
35
0F0164A
1
HINGE TYPE A WITH STUDS, SOCKET
36
036261
6
RIVET POP 0.125" X 0.275"
37
0E7571
2
BALL STUD, GAS SPRING MOUNT
38
027028
2
NUT LOCK HEX 5/16-18 NYL INSRT
39
0E7725
1
BRACKET, GAS SPRING
40
0E6513
1
ASSEMBLY, ROOF
41
0E5298F
1
FOAM, 400 X 220 THERMAL ACOUSTIC
42
0E5298E
1
FOAM, 421.5 X 220 THERMAL ACOUSTIC
43
0E4380
1
COVER, BACK EXHAUST ENCLOSURE
44
0E4382
1
COVER, FRONT EXHAUST ENCLOSURE
45
0E5298
1
FOAM, 746 X 296.5 THERMAL ACOUSTIC
ITEM PART NO. QTY. DESCRIPTION
46
0E5297A
1
FOAM, BACK PANEL THERMAL
ACOUSTIC
47
0E5297D
1
FOAM, FRONT PANEL THERMAL
ACOUSTIC
48
0E5297B
1
FOAM, FRONT PANEL THERMAL
ACOUSTIC
49
0E5297C
1
FOAM, BACK PANEL THERMAL
ACOUSTIC
50
0E4385
1
DUCT, EXHAUST
51
0D3037A
1
LATCH, 1/4 TURN NONLOCKING
52
0C7781A
1
PAWL, DOOR
53
0E5298C
1
FOAM, 646 X 447 THERMAL ACOUSTIC
54
0E5298D
1
FOAM, 610 X 452 THERMAL ACOUSTIC
55
0E4813
1
BAFFLE FRONT EXHAUST DIVIDER
56
0E4384
1
BAFFLE BACK EXHAUST DIVIDER
57
0E4783
1
DEFLECTOR, EXHAUST
58
0E6005
1
DEFLECTOR, ALTERNATOR AIR
59
042907
2
SCREW HHC M8-1.25 X 16mm
60
022145
7
WASHER FLAT 5/16"-M8
61
040976
4
SCREW SHC M8-1.25 X 20mm
62
0E5267
1
MUFFLER
63
0E3156
1
BRACKET, MUFFLER
64
0D5823
2
BOLT U 5/16"-18 X 1.62" WITH SADDLE
65
025145
1
BOLT U 5/16"-18 X 1.25" WITH SADDLE
66
0E3206
1
TUBE, MUFFLER INLET
67
0E7550
1
DEFLECTOR, EXHAUST
68
0E5268
1
TAILPIPE, SS HSB EXHAUST
69
0D9166
1
ASSEMBLY, TWIN REGULATOR
70
0E5968
9.3'
GASKET, EXTRUDED TRIM
71
0E6820
1
GASKET, SCROLL
72
087233
5
RIVET POP 0.187" X 0.450"
73
0E5298A
1
FOAM, 746 X 92.5 THERMAL ACOUSTIC
74
0E5298B
1
FOAM, 746 X 42.5 THERMAL ACOUSTIC
75
0E5298G
1
FOAM, 646 X 86.8 THERMAL ACOUSTIC
76
0E2833D
1
SHEET, HARDWRE CLOTH 787 X 267
77
0D7176
14
WASHER SELF LOCKING
79
045771
2
NUT HEX M8-1.25 G8
80
0A1658
1
WASHER LOCK SPECIAL 1/4"
81
022237
1
WASHER LOCK 3/8"
82
022131
1
WASHER FLAT 3/8"
83
031791
2
CLAMP CABLE 0.48" X 0.204" PLASTIC
84
025034
1
PLUG STEEL 1.06"
85
0E5298H
1
FOAM, 110 X 452 THERMAL ACOUSTIC
86
0E5298J
1
FOAM, 146 X 447 THERMAL ACOUSTIC
87
0E5298K
1
FOAM, 146 X 86.8 THERMAL ACOUSTIC
Section 8 — Exploded Views and Parts Lists
Air-cooled 11 kW Generators
Enclosure – Drawing No. 0E4884-B
