-20-
model g0738 (mfg. since 1/12)
Replacing Fuse
the fuse on the control panel will blow in the case
of a thermal overload.
replace the fuse only with a fast-acting, 2 amp,
250v fuse (F2A250v). the correct fuse is avail-
able from grizzly as part number p0738055.
Tool Needed Qty
phillips screwdriver #2 ...................................... 1
To replace the machine fuse:
1. disConnECt mAChinE From poWEr!
2. Unthread the fuse holder cap from the control
panel (see Figure 16) and remove it. the
fuse will come out with it.
3. replace the fuse and fully thread the cap in
to secure it.
Remote control
battery Replacement
the remote control uses two AA batteries. to
replace them, slide the battery compartment
cover down and off the remote (see
Figure 17).
insert the batteries in the proper direction and
replace the cover.
Figure 16. Fuse holder cap on the control panel.
Fuse
holder Cap
Figure 17. remote control battery compartment
cover removed.
Batteries
Cover
