Installation Preparation
PARTS PROVIDED
Locate the parts packed with the hood.
HARDWARE PACKAGE
Locate and check
contents. Screws
shown actual size.
2 Grease trays (3 with 54" hood)
Implement rods with standoffs
Duct collar
Support frame for 8 ft. ceiling
with 4 large pan head screws
installed on the bottom corners.
2-piece decorative duct cover
Transition with Damper
Decorative top cover
2 Filters (3 with 54" hood)
ACCESSORY PACKAGE
Check accessory package.
Select the taller set for 9’6" to 10’4" ceilings.
Select the shorter set for 8’6" to 9’6" ceilings.
Discard unused set.
2 Templates
Allen Wrench
Screws A
4 (7/16")
hex head
wood
screws
Screws B
2 (1/8" x 1-1/2")
Phillips
pan head
screws.
Screws C
8 blunt point
Phillips
screws
Screw F
Blower safety screw and lock washer,
Phillips head M 6 x 16.
Note: Hardware appearance may vary slightly.
Screws E
2 Phillips
head wood
screws
2 Support Frames
with 8 height
adjustment
screws
2 Sets of Duct Covers
4 Attachment Screws
Screws D
2 small
Phillips
head
screws
