Goodman Mfg RP-526A - Manual (Page 5)

Top Panel/Tubing Assy
Ref.
No: Part
No:
Description:
Ref.
No: Part
No:
Description:
Image 1:
INSULATED ASSY, TOP PANEL 0270L00086S 11
COND MOTOR 1/3 HP, 1 SP, 6 PL (M17, M18) 0131M00008PS 21
COND MOTOR 1/3 HP, 460V (M19, M20) B13400249S 21
COND MOTOR 1/4 HP, 1 SP, 6 PL (M1, M2, M5,
M6, M11, M12) 0131M00007PS 21
COND MOTOR 380/460 50/60 CYCLE (M3, M4, M7,
M8, M13, M14) B13400269S 21
COND MOTOR 575V (M9, M10, M15, M16) 0131M00098S 21
COND MOTOR 575V (M21, M22) 0131M00100S 21
ACORN NUT 5/16 HEX BLACK (QTY 4) 0163M00006P 31
FAN GRILLE 0152G00002S 41
PVC CONDUIT 8.25" 17788000083F 51
FAN BLADE 0150G00001S 61
VENTURI RING 22" 0161L00000 71
Image 2:
ACCUMULATOR (M1, M2, M3, M4) B1226206 12
ACCUMULATOR .875 (M5, M6, M7, M8, M9, M10,
M11, M12, M13, M14, M15, M16, M17, M18, M19,
M20, M21, M22) B1226207 12
CUT-OUT SWITCH, LOW PRESSURE 0130L00007 22
SOLENOID COIL B1225022S 32
SIDE RAIL (QTY 2) 0121L00244RF 42
BI-FLOW FILTER DRIER (M17, M18, M19, M20,
M21, M22) 20485201 52
BI-FLOW FILTER DRIER, STEEL (M1, M2, M3, M4,
M5, M6, M7, M8, M9, M10, M11, M12, M13, M14,
M15, M16) B1219204 52
REVERSING VALVE (M1, M2, M3, M4) B1227316S 62
REVERSING VALVE (M5, M6, M7, M8, M9, M10,
M11, M12, M13, M14, M15, M16, M17, M18, M19,
M20, M21, M22) B1227318S 62
CUT-OUT SWITCH, HIGH PRESSURE 0130M00055 72
COMPRESSOR GROMMET (QTY 4) B1339533 82
END RAIL (QTY 2) 0121L00245 92
TF SHOULDER SCREW (QTY 4) M0221641 102
COMPRESSOR 31200, 200/230/60/3 (M1, M2) ZP31K5ETF5830 112
COMPRESSOR 31200, 460/60/3 (M3, M4) ZP31K5ETFD830 112
COMPRESSOR 39000, 200/230/60/3 (M5, M6) ZP39K5ETF5830 112
COMPRESSOR 39000, 460/60/3 (M7, M8) ZP39K5ETFD830 112
COMPRESSOR 39000, 575/60/3 (M9, M10) ZP39K5ETFE830 112
COMPRESSOR 51000, 208/230/60/3 (M11, M12) ZP51K5ETF5830 112
COMPRESSOR 51000, 460/60/3 (M13, M14) ZP51K5ETFD830 112
COMPRESSOR 51000, 575/60/3 (M15, M16) ZP51K5ETFE830 112
COMPRESSOR 61500, 200/230/60/3 (M17, M18) ZP61KCETF5830 112
COMPRESSOR 61500, 460/60/3 (M19, M20) ZP61KCETFD830 112
COMPRESSOR 61500, 575/60/3 (M21, M22) ZP61KCETFE830 112
COMPRESSOR MOUNTING PLATE 0121L00309 122
COMPRESSOR SCROLL HARNESS 0159L00028 NS
Expanded Model Nomenclature
M1 - CPH036XXX3BXJXBA
M2 - CPH036XXX3BXXXBA
M3 - CPH036XXX4BXJXBA
M4 - CPH036XXX4BXXXBA
M5 - CPH048XXX3BXJXBA
M6 - CPH048XXX3BXXXBA
M7 - CPH048XXX4BXJXBA
M8 - CPH048XXX4BXXXBA
M9 - CPH048XXX7BXJXBA
M10 - CPH048XXX7BXXXBA
M11 - CPH060XXX3BXJXBA
M12 - CPH060XXX3BXXXBA
M13 - CPH060XXX4BXJXBA
M14 - CPH060XXX4BXXXBA
M15 - CPH060XXX7BXJXBA
M16 - CPH060XXX7BXXXBA
M17 - CPH072XXX3BXJXBA
M18 - CPH072XXX3BXXXBA
M19 - CPH072XXX4BXJXBA
M20 - CPH072XXX4BXXXBA
M21 - CPH072XXX7BXJXBA
M22 - CPH072XXX7BXXXBA
