Control Box Assy
Ref.
No:
Part
No:
Description:
Ref.
No:
Part
No:
Description:
Image 1:
DEFROST CONTROL BOARD
PCBDM101S
11
TRANSFORMER 208/230, 24V (M1, M2, M5, M6,
M11, M12, M17, M18)
B1141643
21
TRANSFORMER 480V, 75VA, RESETTABLE (M3,
M4, M7, M8, M13, M14, M19, M20)
B1141672
21
TRANSFORMER 575/24V (M9, M10, M15, M16,
M21, M22)
0130M00045S
21
24V RELAY (M3, M4, M7, M8, M9, M10, M13, M14,
M15, M16, M19, M20, M21, M22)
0130M00025S
31
CONTACTOR 25 AMP, 3P, 24V (M3, M4, M7, M8,
M9, M10, M13, M14, M15, M16, M19, M20, M21,
M22)
CONT3P025024VS
41
CONTACTOR 30 AMP, 3P, 24V (M1, M2, M5, M6,
M11, M12, M17, M18)
CONT3P030024VS
41
CAPACITOR 5/370V
CAP050000370VAS
51
TERMINAL BOARD
0130M00038S
61
BOARD, ELECTRONIC BLOWER TIME DELAY
RELAY
PCBFM103S
71
CAPACITOR STRAP
20520901
NS
CONTROL HARNESS
0259L00076
NS
DEFROST HARNESS (M1, M2, M5, M6, M11, M12,
M17, M18)
0259L00077
NS
DEFROST HARNESS (M3, M4, M7, M8, M9, M10,
M13, M14, M15, M16, M19, M20, M21, M22)
0259L00078
NS
WIRING HARNESS
0259L00057
NS
WIRING HARNESS
0259L00061
NS
WIRING HARNESS (M1, M2, M3, M4, M5, M6, M7,
M8, M9, M10, M11, M12, M13, M14, M15, M16)
0259L00065
NS
WIRING HARNESS (M1, M2, M5, M6, M9, M10,
M11, M12, M15, M16, M17, M18, M21, M22)
0259L00070
NS
WIRING HARNESS (M3, M4, M7, M8, M13, M14,
M19, M20)
0259L00071
NS
WIRING HARNESS (M17, M18, M19, M20, M21,
M22)
0259L00094
NS
Expanded Model Nomenclature
M1 - CPH036XXX3BXJXBA
M2 - CPH036XXX3BXXXBA
M3 - CPH036XXX4BXJXBA
M4 - CPH036XXX4BXXXBA
M5 - CPH048XXX3BXJXBA
M6 - CPH048XXX3BXXXBA
M7 - CPH048XXX4BXJXBA
M8 - CPH048XXX4BXXXBA
M9 - CPH048XXX7BXJXBA
M10 - CPH048XXX7BXXXBA
M11 - CPH060XXX3BXJXBA
M12 - CPH060XXX3BXXXBA
M13 - CPH060XXX4BXJXBA
M14 - CPH060XXX4BXXXBA
M15 - CPH060XXX7BXJXBA
M16 - CPH060XXX7BXXXBA
M17 - CPH072XXX3BXJXBA
M18 - CPH072XXX3BXXXBA
M19 - CPH072XXX4BXJXBA
M20 - CPH072XXX4BXXXBA
M21 - CPH072XXX7BXJXBA
M22 - CPH072XXX7BXXXBA
