Belt Drive Assy
Ref.
No:
Part
No:
Description:
Ref.
No:
Part
No:
Description:
Image 1:
BELT DRIVE MOTOR (230/460)/60/3P (M17, M18,
M19, M20)
B3240007
11
BELT DRIVE MOTOR 1 HP (M1, M2, M3, M4, M5,
M6, M7, M8, M11, M12, M13, M14)
0131L00003S
11
BELT DRIVE MOTOR 1.5 HP 575V (M9, M10, M15,
M16, M21, M22)
0131L00004S
11
BLOWER SIDE ANGLE (QTY 3)
0121L00297
21
MOTOR MOUNT PLATE
0121L00271
31
MOTOR MOUNT ANGLE
0121L00272
41
BELT DRIVE BLOWER SHAFT
0163L00005
51
BLOWER HOUSING 11 X 10
2539302FS
61
MOUNTING BRACKET BEARING (QTY 2)
B3201300
71
BELT DRIVE BLOWER WHEEL
B1368056
81
FIXED SHEAVE (M1, M2, M3, M4)
B2120011
91
FIXED SHEAVE AK59 (M17, M18, M19, M20, M21,
M22)
0163L00031
91
FIXED SHEAVE AK61 (M11, M12, M13, M14, M15,
M16)
B3204303
91
FIXED SHEAVE AK66 (M5, M6, M7, M8, M9, M10)
B3204310
91
STEEL KEY (000158812) 2.0"
B1398604
101
BALL BEARING 1.00" (QTY 2)
B1399500
111
FAN BELT, NOTCHED
0164L00003
121
VARIABLE PITCH SHEAVE 1VL40 X 5/8" (M1, M2,
M3, M4)
0163L00024
131
VARIABLE PITCH SHEAVE 1VL44 X 3/8" (M5, M6,
M7, M8, M9, M10, M11, M12, M13, M14, M15, M16)
B2120001
131
VARIABLE PITCH SHEAVE 1VL44 X 7/8" (M17,
M18, M19, M20, M21, M22)
B2120014
131
MOTOR PIVOT ANGLE
0121L00273
141
ELECT. CONNECTING BUSHING
B1393726
151
BOLT
0163M00054
161
BOLT 1/4-20 X 3/4" (QTY 4)
B1393738
171
MOTOR ADJUST BRACKET
0121L00274
181
ACORN NUT 5/16 X 18
0163M00055
191
FLANGED LOCKNUT 5/16-18TPI
B1393020
201
HEX NUT INSERT 5/16-18 (QTY 5)
B1393027
211
MOUNTING BRACKET INSERT
0121L00275
221
BELT DRIVE BLOWER CUT-OFF
1864700F
NS
STEEL KEY (000158812) 4.5"
B1398603
NS
Expanded Model Nomenclature
M1 - CPH036XXX3BXJXBA
M2 - CPH036XXX3BXXXBA
M3 - CPH036XXX4BXJXBA
M4 - CPH036XXX4BXXXBA
M5 - CPH048XXX3BXJXBA
M6 - CPH048XXX3BXXXBA
M7 - CPH048XXX4BXJXBA
M8 - CPH048XXX4BXXXBA
M9 - CPH048XXX7BXJXBA
M10 - CPH048XXX7BXXXBA
M11 - CPH060XXX3BXJXBA
M12 - CPH060XXX3BXXXBA
M13 - CPH060XXX4BXJXBA
M14 - CPH060XXX4BXXXBA
M15 - CPH060XXX7BXJXBA
M16 - CPH060XXX7BXXXBA
M17 - CPH072XXX3BXJXBA
M18 - CPH072XXX3BXXXBA
M19 - CPH072XXX4BXJXBA
M20 - CPH072XXX4BXXXBA
M21 - CPH072XXX7BXJXBA
M22 - CPH072XXX7BXXXBA
