Page 3
Functional Parts
Part
No:
Description:
0130M00025S
24V RELAY (M3, M4, M7, M8, M9, M10, M13,
M14, M15, M16, M19, M20, M21, M22)
PCBFM103S
BOARD, ELECTRONIC BLOWER TIME
DELAY RELAY
CAP050000370VAS CAPACITOR 5/370V
ZP31K5ETF5830
COMPRESSOR 31200, 200/230/60/3 (M1, M2)
ZP31K5ETFD830
COMPRESSOR 31200, 460/60/3 (M3, M4)
ZP39K5ETF5830
COMPRESSOR 39000, 200/230/60/3 (M5, M6)
ZP39K5ETFD830
COMPRESSOR 39000, 460/60/3 (M7, M8)
ZP39K5ETFE830
COMPRESSOR 39000, 575/60/3 (M9, M10)
ZP51K5ETF5830
COMPRESSOR 51000, 208/230/60/3 (M11,
M12)
ZP51K5ETFD830
COMPRESSOR 51000, 460/60/3 (M13, M14)
ZP51K5ETFE830
COMPRESSOR 51000, 575/60/3 (M15, M16)
ZP61KCETF5830
COMPRESSOR 61500, 200/230/60/3 (M17,
M18)
ZP61KCETFD830
COMPRESSOR 61500, 460/60/3 (M19, M20)
ZP61KCETFE830
COMPRESSOR 61500, 575/60/3 (M21, M22)
0131M00008PS
COND MOTOR 1/3 HP, 1 SP, 6 PL (M17, M18)
B13400249S
COND MOTOR 1/3 HP, 460V (M19, M20)
0131M00007PS
COND MOTOR 1/4 HP, 1 SP, 6 PL (M1, M2,
M5, M6, M11, M12)
B13400269S
COND MOTOR 380/460 50/60 CYCLE (M3,
M4, M7, M8, M13, M14)
0131M00098S
COND MOTOR 575V (M9, M10, M15, M16)
0131M00100S
COND MOTOR 575V (M21, M22)
CONT3P025024VS
CONTACTOR 25 AMP, 3P, 24V (M3, M4, M7,
M8, M9, M10, M13, M14, M15, M16, M19, M20,
M21, M22)
CONT3P030024VS
CONTACTOR 30 AMP, 3P, 24V (M1, M2, M5,
M6, M11, M12, M17, M18)
0130M00055
CUT-OUT SWITCH, HIGH PRESSURE
0130L00007
CUT-OUT SWITCH, LOW PRESSURE
0130M00056
DEFROST CONTROL (M1, M2, M3, M4, M5,
M6, M7, M8, M9, M10, M11, M12, M13, M14,
M15, M16)
PCBDM101S
DEFROST CONTROL BOARD
0130M00038S
TERMINAL BOARD
B1141643
TRANSFORMER 208/230, 24V (M1, M2, M5,
M6, M11, M12, M17, M18)
B1141672
TRANSFORMER 480V, 75VA, RESETTABLE
(M3, M4, M7, M8, M13, M14, M19, M20)
0130M00045S
TRANSFORMER 575/24V (M9, M10, M15,
M16, M21, M22)
SPECIAL PARTS
IO-354A
INSTALLATION INSTRUCTIONS
RP-526A
REPAIR PARTS MANUAL
B1757910
SUPPLEMENTAL INSERT (EBTDR)
Expanded Model Nomenclature
M1 - CPH036XXX3BXJXBA
M2 - CPH036XXX3BXXXBA
M3 - CPH036XXX4BXJXBA
M4 - CPH036XXX4BXXXBA
M5 - CPH048XXX3BXJXBA
M6 - CPH048XXX3BXXXBA
M7 - CPH048XXX4BXJXBA
M8 - CPH048XXX4BXXXBA
M9 - CPH048XXX7BXJXBA
M10 - CPH048XXX7BXXXBA
M11 - CPH060XXX3BXJXBA
M12 - CPH060XXX3BXXXBA
M13 - CPH060XXX4BXJXBA
M14 - CPH060XXX4BXXXBA
M15 - CPH060XXX7BXJXBA
M16 - CPH060XXX7BXXXBA
M17 - CPH072XXX3BXJXBA
M18 - CPH072XXX3BXXXBA
M19 - CPH072XXX4BXJXBA
M20 - CPH072XXX4BXXXBA
M21 - CPH072XXX7BXJXBA
M22 - CPH072XXX7BXXXBA
3
RP-526A
