Gemini ps-02usb User Manual
Page 6
is assigned to USB 1 (9).
2. USB 2 (11) can be assigned to CH 2, CH 3, or turned O
FF
.
During playback, the signal from the computer will be sent into the CH 2
F
ADER
(24), G
AIN
& EQ C
ONTROLS
(30) & C
UE
S
ECTION
(21, 27) when CH 2
is assigned to USB 2 (11).
During playback, the signal from the computer will be sent into the CH 3
F
ADER
(25), G
AIN
& EQ C
ONTROLS
(31) & C
UE
S
ECTION
(21, 27) when CH 3
is assigned to USB 2 (11), the signal coming from CH 3, PH 3/LN 5 (14)
or LN 6 (13).
You should turn O
FF
each port if you are not sending music from your
computer through the mixer via USB cables. Monitoring the computer’s
audio signal through the USB P
ORTS
(9, 11) is not allowed when O
FF
is
selected on the USB A
SSIGN
S
WITCHES
(10, 12).
R
ECORDING
V
IA
USB:
This mixer is compatible with most wave editing software programs. You
may record from each USB P
ORT
(9, 11) simultaneously onto the comput-
er regardless of the USB assignment. When recording onto your comput-
er, the signal coming from CH 1 (17, 18) will be sent to the computer via
USB 1 P
ORT
(9). The signal coming from PGM outputs (M
ASTER
(5),
R
ECORD
(6), Z
ONE
(7)) will be sent to the computer via USB 2 P
ORTS
(11).
When the USB A
SSIGN
S
WITCHES
(10, 12) are O
FF
you may still record onto
the computer.
SPECIFICATIONS:
I
NPUTS
:
Phono...................................................................................3 mV, 47 KOhm
Line..................................................................................150 mV, 27 KOhm
MIC.....................................................................1.5 mV, 1 K Ohm Balanced
MIC Bass.........................................................................................± 12 dB
MIC High........................................................................................± 12 dB
O
UTPUTS
:
Amp/Zone.......................................................................0 dB 1 V, 400 Ohm
Max...................................................................................20 V Peak-to-Peak
Rec.....................................................................................225 mV, 5 KOhm
Balanced Master......................................................................2 V, 400 Ohm
G
ENERAL
:
Frequency Response................................................20Hz - 20KHz +/- 2 dB
Distortion.......................................................................................< 0.02%
S/N Ratio..........................................................................Better Than 80 dB
Headphone Impedance...................................................................16 Ohm
Power Source......................................................115/230 V, 60/50 Hz, 20 W
Unit Dimensions.............................................................10" x 3.3" x 10.25"
.....................................................................................(254 x 84 x 260 mm)
Weight...............................................................................8.84 .lbs (4.01kg)
S
PECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTIFICATION FOR IMPROVEMENT
.
6
