5.2.9
QPRJ-SSC, “3 + 1” 3@10/100Mb RJ-45 and 1@100Mb Fiber SC
Single-mode Connector, “Combo” Quad-Port Module
The Magnum QPRJ-SSC is also a 3+1 Combo quad-port module. It is the
same as the QPRJ-MSC “3+1 combo” module except the fiber port is single-mode. See
Section 5.2.3 for a description of the 100Mb single-mode fiber port.
5.2.10 QPM-FP
The QPM-FP is a blank face plate or cover plate that must be installed in any
empty QPM slots to maintain proper
cooling air flow, and for safety, etc.
Two screws underneath
the front panel hold the QPM-FP in
place.
Fig. 5.2.10 Blank Face Plate
