-12-
G8030 3 H.P. Overarm Router
The air line control is used to check and control air
flow to the chip blower.
1.
Turn control on and off to see if pressure exists
as shown in
Figure 6
.
2
. Adjust flow to most effectively remove chips
from the line of sight.
Figure 5.
Lift and turn cap to adjust air
pressure. Turn lube valve to lubricate
foot switch control.
4.
Connect an air compressor to the regulator. Air
pressure must be 90 pounds per square inch.
5.
To raise the air pressure, lift the air unit cap
and turn it counterclockwise as shown in
Figure 5.
Cap
Lube Valve
Figure 6.
Air line control for chip blower.
Chip Blower
Compressed air can be very dangerous if
not handled carefully. Never point an air
hose nozzle or blower towards any person,
including yourself. Failure to comply with
this caution could result in serious injury.
