CHECK INSTALLATION HARDWARE
Locate the hardware accessory box packed with the hood and check contents.
Installation Preparation
29-7/8"
11-1/2"
12"
27-3/4"
Mounting bracket
1 charcoal filter for
recirculating installation
2-piece decorative duct
cover (dimension shown
for reference only)
Air deflector for
recirculating
installation only
Duct bracket
14-5/8 ″ to top of bracket
C L
▼
ALIGN BOTTOM EDGE WITH PENCIL LINE, INDICATING BOTTOM OF THE HOOD
Drill 2 (two) 3/16 ″ pilot holes through studs or rear wall support
REAR WALL
MOUNTING TEMPLATE
49-80405 04-06 JR
Wall mount template
8
HARDWARE PACKAGE
Locate and count
screws
3 wood
screws
3 wall
fasteners
3 wall bracket
screws
12 hood
attachment
screws
27-3/4”
12-7/8”
23-7/8”
11-1/2”
Stainless steel filter
2 thumb
screws
